FANTECH VHR 150R Air Exchanger Greater Montreal
Is it the right size for your home?
It delivers 155 cfm net, enough to ventilate 1,800 to 2,900 sq ft. Choose your home's living area.
It's the right size.
For a 1,500 to 2,500 sq ft home, about 105 cfm of air needs to be renewed continuously. This unit delivers 155 cfm net — enough for the house, with extra capacity to boost ventilation for the bathroom and kitchen.
Calculation: 0.35 air changes per hour over the living volume, with 9 ft ceilings. Our estimator sets the exact airflow room by room, following CSA F326.
What it does, in numbers
$71.25
Electricity per year
Less than a 100 W light bulb
Bulbs left on day and night. Same calculation for every line: wattage × 8,760 h × 11.142 ¢/kWh.
Meets the Québec Construction Code everywhere in the province. The Code requires 54% at −25 °C below 6,000 degree-days (Montréal, Laval, Longueuil and both shores) and 60% above that. This unit is rated at 60% at 89 cfm.
Airflow and efficiency: manufacturer's published data. Cost: 73 W over 8,760 h at Hydro-Québec's Rate D second tier (11.142 ¢/kWh).
What you should know about this one
Published, verifiable facts, not brochure claims.
6 in oval6 in oval collars with a balancing damper
The plastic oval collars include a balancing damper and airflow measurement ports, so balancing is done at the unit. Fantech publishes a 90 to 170 cfm balancing range for this model.
SwitchLow / standby / medium switch on the unit
The VHR 150R has a three-position rocker switch (low, standby, medium) that provides continuous ventilation even without a wall control. Fantech offers ECO-Touch, EDF7, EDF1R, RTS2, RTS5 and MDEH1 controls as options.
60%What it still recovers at −25 °C
The only efficiency figure that matters for a Québec winter, and the one the Code uses. An efficiency quoted without its temperature means nothing; this one is measured at a test airflow of 89 cfm.
DamperIt defrosts without depressurizing the house
In cold weather, a motorized damper closes the outdoor air intake and recirculates indoor air through the core to thaw it. The house doesn't go into negative pressure during the cycle: no cold air drawn in through leaks, and none of the imbalance manufacturers warn about when there's a fireplace or a combustion appliance.
HRVIt recovers heat, not moisture
Excess moisture leaves the house. In Québec, that's the right choice in most cases: in winter, the problem is almost always too much humidity, not too little.
−21 cfmWhat the ducts cost it
Between a nearly unrestricted test bench (0.2 in) and a real duct system (0.4 in), it drops from 176 to 155 cfm. Most spec sheets show only the first number, precisely because it looks better.
73 WMeasured at the airflow it actually runs at
Its 66% at 0 °C is measured at 85 cfm, the continuous airflow of a typical home. At that setting it draws 73 W, or about 639 kWh a year.
LifetimeThe core warranty
The core does the work and is the most expensive part to replace. Motors: 7 years. Parts: 5 years. We register the warranty in your name at commissioning.
6 inWhat it needs on site
6 in (oval) ducts, top connection and a condensate drain. It weighs 44 lb, and it needs enough clearance to slide the core out once a year.
What it needs on site
In a condo with no floor drain, or with little ceiling clearance, we usually look at a side-port model instead. Our estimator checks the location, the drain and the duct route before ordering.
Complete spec sheetData and cited sources
- Net airflow at 0.2 in. w.g.
- 176 cfm
- Net airflow at 0.4 in. w.g.
- 155 cfm
- SRE at 0 °C (85 cfm)
- 66%
- SRE at −25 °C (89 cfm)
- 60%
- ASE at 0 °C
- 79%
- Power draw
- 73 W
- Efficacy
- 1.2 cfm/W
- Type
- HRV
- Connection
- Top ports
- Duct collars
- 6 in (oval)
- Condensate drain
- Required
- Defrost cycle
- Recirculation (motorized damper)
- Filters
- 2 washable electrostatic panel filters (8.5 × 15 in)
- Dimensions (L × D × H)
- 23.75 × 17.19 × 16.25 in
- Weight
- 44 lb
- Power supply
- 120 V
- Warranty — core
- Lifetime
- Warranty — motors
- 7 years
- Warranty — parts
- 5 years
Airflow and efficiency: manufacturer's published data. Annual consumption calculated at 73 W running continuously for 8,760 h, at Hydro-Québec's Rate D second tier (11.142 ¢/kWh), in effect since April 1, 2026.
The next model down and up
Talk to an HVAC technician before you choose
We calculate the airflow room by room, check the location and the drain, and give you an installed price. Balancing is measured at commissioning, not estimated.
Fantech VHR 150R: The Ultimate Solution for Indoor Air Quality
We are AirGreen, a Heating, Ventilation and Air Conditioning (HVAC) company based in Montréal. We specialize in selling and installing air exchangers, with one of our top products being the Fantech VHR 150R Air Exchanger. This detailed guide will provide you with an in-depth understanding of the features and benefits of this innovative air exchange system.
In the quest for improved indoor air quality and energy efficiency, the Fantech VHR 150R Air Exchanger stands out with its advanced features. With its compact design and oval duct connections, this product offers a solution for a healthier and more comfortable indoor environment.
A Glimpse into the World of Air Exchangers
An air exchanger is an essential component of any modern HVAC system. It ensures fresh air supply and removes stale air from indoors, maintaining a balanced, healthier environment. The Fantech VHR 150R is a remarkable air exchanger that combines efficiency, convenience, and high performance.
Why Choose Fantech VHR 150R?
The Fantech VHR 150R stands out for its superior functionality, easy installation, and exceptional performance. It offers a range of features designed to ensure optimal indoor air quality and energy efficiency.
Fantech VHR 150R Specifications
The Fantech VHR 150R is specifically designed to fit your space requirements, offering features such as:
- Duct size: 6" (152 mm) oval.
- Voltage/Phase: 120/1.
- Power rated: 156 W.
- Amp: 1.4 A.
Heat Recovery Core
The aluminum heat recovery core is configured for efficient cross-flow ventilation. It measures 9" x 9" (229 x 229 mm) with a 15" (380mm) depth. Cores are manufactured to withstand extreme temperature variations.
Wintergard™ Defrost System
The VHR 150R incorporates a unique and quiet internal recirculation defrost that does not depressurize the home during the defrost cycle. A preset defrost sequence is activated when the outdoor temperature falls below 23°F (-5°C) and automatically adjusts itself based on operating conditions. The fan speed is also adjusted automatically to provide a smooth and quiet transition between Ventilation & Defrost mode.
Serviceability
Core, filters, fans, drain pan, and electrical panel can be easily accessed from the access panel. Core conveniently slides out with only 17” (432 mm) clearance.
Duct Connections
6" (152 mm) Oval plastic duct connections with integrated balancing damper and airflow measurement ports.
Case
24 gauge galvanized steel. Baked powder-coated paint.
Insulation
The cabinet is fully insulated with 1” (25 mm) high-density expanded polystyrene.
Filters
Two (2) washable electrostatic panel-type air filters 8.5” (216mm) x 15” (380 mm) x 0.125” (3mm).
Controls
An external three (3) position (Low/Stand By/Medium) rocker switch that offers continuous ventilation. Fantech offers a variety of external controls.
Installation
The unit is typically hung by using the installation kit supplied with the unit. Mounting bolts are provided on the top four (4) corners of the unit.
Warranty
Limited lifetime on aluminum core, 7-year on motors, and 5-year on parts.
In conclusion
The Fantech VHR 150R is a wise investment for those looking to improve the indoor air quality of their home. By investing in this product, you can benefit from improved comfort, better health, and energy savings. So don't wait any longer and breathe cleaner air with the Fantech VHR 150R.
