Installation of a GREE CLIVIA R32 wall-mounted heat pump in Pointe-Calumet: a compact, clean, and well-integrated HVAC solution for a residential home
AirGreen installs a GREE CLIVIA R32 wall-mounted heat pump in Pointe-Calumet: compact mini-split solution, clean finish, optimized residential comfort, and HVAC expertise on the North Shore.
Take a tour of the installation
Each number is a point we check on site. Switch between summer and winter to watch air and heat move.
In summer, the outdoor unit rejects the house's heat outside.
Generic illustration of this type of installation, not a survey of this job site. Tap a number.
Mounted level on a wall plate, high enough for the air to reach the whole room, with enough space around it to slide the filters out easily.
The refrigerant lines, the communication cable and the drain go through the wall in a single opening, sealed against water, cold air and insects.
Two insulated copper pipes connect the two units. Outside, a line cover can protect them from sun, knocks and weather.
A shut-off switch near the outdoor unit isolates it safely for service. It must stay accessible at all times.
The compressor and the fan. In heating mode it captures heat from the outdoor air, even in winter, and moves it inside.
On the ground or on the wall, it keeps the unit above accumulated snow. The unit stays clear and defrost water can drain away.
The fan needs to blow freely. Storage, a fence or a wall too close, and efficiency drops while noise goes up.
A Meticulous Installation in Pointe-Calumet, Designed for Comfort Without Compromising Exterior Appearance
In Pointe-Calumet, on the North Shore, our AirGreen team recently completed the installation of a GREE CLIVIA R32 wall-mounted heat pump, a wall-mounted air conditioner – mini split – wall-mounted heat pump type system, designed to offer effective comfort in summer as well as during colder periods of the year. This intervention perfectly illustrates what many single-family homeowners in the greater Montreal area are looking for: a high-performance, discreet, well-installed HVAC solution adapted to the actual constraints of the building.
From the first glance at the outdoor installation, several elements stand out. The GREE unit was positioned at the bottom of the wall, on solid wall brackets, in a confined space between a section of pale exterior siding, a brick facade, a window, and existing plantings. The challenge was not just to install a heat pump: it was necessary to integrate the appliance into an already developed environment, without hindering air circulation, without compromising the aesthetics of the property, and without creating unnecessary obstacles near the house.
At AirGreen, this type of installation requires careful planning. A successful HVAC installation is never limited to the choice of machine. It also depends on the exact location of the outdoor unit, the protection of the refrigerant lines, drainage management, cable routing, clearance around the condenser, and the ability to respect the specific characteristics of the building. In this project in Pointe-Calumet, every detail was adjusted to achieve a clean, durable, and easy-to-maintain result.
Why the GREE CLIVIA R32 Model Was Relevant for This Residence
The GREE CLIVIA R32 range is particularly interesting for homeowners looking for a modern, reliable, and efficient wall-mounted heat pump, while benefiting from R32 refrigerant technology. This refrigerant is increasingly used in recent residential systems, notably because it allows for good energy efficiency with a charge generally optimized compared to some older refrigerants.
In the context of a residence in Pointe-Calumet, where needs can vary greatly between hot and humid summer days and auxiliary heating periods in spring, fall, and sometimes winter, a GREE wall-mounted heat pump represents a very versatile solution. It allows for quick air conditioning of a living area, stabilizes indoor temperature, and reduces reliance on more energy-intensive heating systems when conditions allow.
The CLIVIA R32 model also stands out for its compact outdoor format, visible in the completed installation. The unit is discreet enough to be integrated along a residential wall, while maintaining the necessary clearance in front of the fan to ensure good heat exchange. This point is crucial: even an excellent appliance can lose performance if its outdoor unit is poorly positioned, too enclosed, or exposed to obstructions.
Technical Analysis of the Site: Limited Space, but Precisely Utilized
The image of this installation shows a frequent reality in residential projects on the North Shore: the available space around the house is useful, but rarely ideal. The outdoor unit had to be installed near the wall, while respecting several constraints:
- presence of a nearby window;
- exterior siding to preserve;
- adjacent brick and existing service drops;
- vegetation and landscaping near the base of the wall;
- future access for HVAC maintenance;
- protection of refrigerant and electrical lines.
Our technicians installed the outdoor unit on wall brackets to avoid direct contact with the ground and limit exposure to water, leaves, mulch, or snow accumulation. This decision is important in Pointe-Calumet, where seasonal variations impose very real constraints on outdoor equipment. An appliance placed too low or directly on an unstable surface can become more difficult to maintain, get dirty more quickly, or suffer more from the effects of freezing and thawing.
The line set was protected by a pale vertical line hide, matching the siding. This choice improves the final appearance while protecting the lines from weather, UV rays, and light impacts. The visual integration is particularly successful: the cover follows a clean vertical line, near the junction between the brick and the siding, which limits the visual impact of the installation.
A Well-Clearanced Outdoor Unit Despite the Presence of Vegetation
A point often overlooked by homeowners when installing a wall-mounted air conditioner or wall-mounted heat pump is the clearance around the condenser. On this project, the presence of plants, rose bushes, and decorative mulch added an additional constraint. The outdoor unit had to be accessible, stable, and capable of discharging hot air without obstruction.
We therefore ensured that a functional space was maintained in front of the fan, while keeping the appliance in an area consistent with the exterior landscaping. This is a critical balance: moving the unit too far away can increase the length of the lines and complicate installation, while placing it too close to vegetation can negatively impact its performance. A professional HVAC installation is precisely about finding the optimal point between performance, aesthetics, accessibility, and durability.
For homeowners in Montreal, Laval, Longueuil, the North Shore, and the South Shore, this installation is a good example of a well-thought-out solution for residential properties where space is shared between technical access, windows, service drops, and landscaping.
An AirGreen Method Focused on Durability, Performance, and Peace of Mind
At AirGreen, we approach every installation as a complete project. The machine installed is important, but the quality of the result primarily depends on all the decisions made before, during, and after the work. For this GREE CLIVIA R32 wall-mounted heat pump in Pointe-Calumet, our team followed a structured approach to ensure a reliable installation that meets the client's expectations.
Assessment of Indoor and Outdoor Location
Before installing a wall-mounted heat pump, it is necessary to validate the location of both the indoor and outdoor units. The goal is to create a logical path between the two, with a reasonable line length, efficient drainage, and comfortable air distribution indoors.
In this type of residence, the indoor unit is generally chosen according to the room configuration: open concept, living room, main hallway, floor to be air-conditioned, or a specific area to be made more comfortable. The GREE CLIVIA R32 can be selected in different capacities depending on the actual needs of the dwelling, the surface area, insulation, solar orientation, number of occupants, and room layout. Good capacity selection is essential: a unit that is too small will run too long without achieving the desired comfort, while an oversized unit can reduce dehumidification quality and cause short cycling.
This is why we never recommend a model based solely on an approximate surface area. We take into account the reality of the house. In Pointe-Calumet, residences can have very different characteristics: houses near the water, bungalows, cottages, extensions, finished basements, sunrooms, large windows, or areas more exposed to the sun. All these elements influence the choice of the heat pump.
Line Protection and Exterior Finish
On this installation, the vertical line hide plays both a technical and aesthetic role. It protects the refrigerant lines, communication cable, and drain according to the system configuration. It also helps maintain a clean facade, without messy exposed lines.
A common mistake in some less meticulous installations is to leave the lines poorly secured, exposed, or misaligned. In the short term, this may seem acceptable, but in the long term, the consequences can be significant: insulation degradation, water infiltration, vibrations, sagging, difficulty of maintenance, or a neglected appearance. For a company specializing in HVAC installation like AirGreen, the finish is not a secondary detail. It is part of the overall quality of the work.
Wall Mounts: Stability and Protection Against Outdoor Conditions
The outdoor unit of this GREE CLIVIA R32 was fixed on wall mounts, an option particularly relevant when you want to keep the unit off the ground. This approach can reduce risks associated with mulch, leaves, water accumulation, or certain winter conditions.
The brackets must be installed solidly, with the correct anchors and precise leveling. A poorly leveled outdoor unit can generate vibrations, hinder the flow of defrost water, or cause premature wear. Conversely, a stable installation helps reduce unwanted noise and extends the system's lifespan.
Commissioning: An Essential Step, Not a Mere Formality
After physical installation, commissioning is a critical step. It includes checking connections, verifying seals, vacuuming refrigerant lines, validating operation, testing air conditioning and heating under possible conditions, and explaining the settings to the client.
For a GREE wall-mounted heat pump, this step confirms that the system responds correctly, that the indoor unit communicates well with the outdoor unit, and that the expected comfort is achieved. Hasty commissioning can lead to problems that could have been avoided from the outset. That's why our technicians follow a rigorous method on every job site, whether in Montreal, Laval, Longueuil, on the North Shore, or on the South Shore.
Customer Experience: More Stable Comfort and a Discreet Installation
The client was looking for an effective solution, but also an installation that would not detract from the exterior of the house. The result meets this objective: the unit is well positioned, the lines are protected, the overall system remains compact, and access to the appliance for maintenance is maintained.
This type of project is often driven by several needs simultaneously: improving comfort during heatwaves, reducing indoor humidity, obtaining efficient auxiliary heating, modernizing an aging system, or adding air conditioning to a house that did not have one. With a GREE CLIVIA R32 wall-mounted heat pump, the homeowner benefits from a flexible solution that can help improve daily comfort without requiring central ducts.
Eligibility for Subsidies: A Point to Validate According to the Exact Model and Capacity
Subsidy programs, particularly those related to Hydro-Québec and efficient equipment, can represent a significant financial advantage for some homeowners. However, eligibility always depends on the specific model, the installed capacity, the official lists in force, and the program conditions at the time of installation.
At AirGreen, we help our clients understand the necessary steps, the documents to keep, and useful information after the work. For a wall-mounted heat pump like the GREE CLIVIA R32, it is important to validate eligibility according to the exact configuration installed. This caution avoids unpleasant surprises and allows the client to better plan their budget.
Practical Tips to Preserve the Performance of Your GREE CLIVIA R32
Once the installation is complete, maintenance plays a major role in long-term performance. A well-maintained heat pump consumes less, operates more quietly, and provides more consistent comfort.
We particularly recommend:
- regularly cleaning the indoor unit filters;
- keeping the area around the outdoor unit clear;
- preventing plants from growing too close to the fan;
- not stacking objects in front of or above the condenser;
- monitoring drain flow;
- scheduling periodic professional HVAC maintenance;
- checking after winter that no debris has accumulated around the appliance.
In the specific case of this installation in Pointe-Calumet, the vegetation around the unit will need to be monitored throughout the seasons. Plants can grow quickly and eventually reduce the necessary clearance. Light and regular pruning will help maintain good airflow.
Mistakes to Avoid During a Wall-Mounted Heat Pump Installation
Many performance problems do not stem from the machine itself, but from poor installation. Among the most frequent mistakes are:
- choosing a BTU capacity without a real assessment of the house;
- installing the outdoor unit too close to a wall, hedge, or obstacle;
- neglecting the slope or protection of the drain;
- leaving lines exposed without adequate line covers;
- placing the indoor unit in a location where air does not circulate well;
- ignoring electrical constraints;
- choosing a contractor who does not offer after-installation service.
An HVAC installation must be conceived as a complete system. The appliance, lines, drainage, electricity, supports, commissioning, and future maintenance must work together. It is this global vision that distinguishes a durable installation from a simple equipment setup.
Why Choose AirGreen for an HVAC Installation in Pointe-Calumet
AirGreen regularly operates in Pointe-Calumet, on the North Shore, as well as throughout Greater Montreal, including Montreal, Laval, Longueuil and the South Shore. Our field experience allows us to offer solutions adapted to local realities: houses with light siding, brick facades, condos, multiplexes, semi-detached houses, narrow lots, neighborhood constraints, co-ownership regulations, and varied technical requirements.
We favor a clear approach: tailored recommendation, clean installation, reliable equipment, understandable explanations, and post-work support. For an owner, this means less uncertainty and greater confidence in the final result.
The installation of this GREE CLIVIA R32 wall-mounted heat pump in Pointe-Calumet perfectly demonstrates this approach. The system is discreet, securely fastened, properly cleared, and carefully integrated into the exterior wall. The lines are protected, the unit is accessible, and the entire setup respects the project's main goal: to offer better indoor comfort with a clean and durable outdoor installation.
A project representative of residential needs on the North Shore
This project perfectly summarizes what many clients are looking for today: an efficient wall-mounted air conditioning solution, a heat pump capable of assisting with heating depending on the season, better controlled consumption, and an installation that does not degrade the appearance of the house.
In Pointe-Calumet, as elsewhere on the North Shore, homeowners often want to improve their comfort without undertaking major renovation work. The mini split system precisely meets this need. It allows for the addition of a high-performance HVAC solution without ductwork, with an installation that is generally quick and minimally invasive when well-planned.
The GREE CLIVIA R32 aligns with this logic: a modern, compact device, well-suited for residential projects, and capable of offering stable comfort when installed according to best practices.
Conclusion: a clean, efficient, and durable installation in Pointe-Calumet
This AirGreen project in Pointe-Calumet highlights the importance of a well-thought-out installation. The choice of a GREE CLIVIA R32 wall-mounted heat pump alone is not enough to guarantee an excellent result. It is the building analysis, precise positioning, quality of supports, protection of lines, commissioning, and attention to detail that transform a good appliance into a durable solution.
For homeowners in Montreal, Laval, Longueuil, the North Shore, and the South Shore, this project is a concrete example of a successful HVAC installation: compact, clean, efficient, and designed for the real comfort of occupants.
The big day, step by step
The main steps of this kind of job at AirGreen. Every house has its quirks: the estimate brings them out.
We look at the room, the outside wall, the line route and where the outdoor unit will go. That is where the capacity gets chosen.
Model, capacity and price, in writing. We also check whether the model qualifies for assistance programs.
Floors and furniture protected, wall plate position marked level, wall opening located.
A single opening, with the slope the drain needs to flow outside.
Set on a stand raised above the snow, with the clearances the manufacturer requires.
Connected, insulated and protected. The opening is then sealed against water, cold air and insects.
A dedicated circuit and an accessible disconnect near the outdoor unit.
Leak test, vacuum, then start-up and a check of heating and cooling.
Remote, modes, filters: we show you the essentials before we leave.
- The on-site estimateWe look at the room, the outside wall, the line route and where the outdoor unit will go. That is where the capacity gets chosen.
- The quoteModel, capacity and price, in writing. We also check whether the model qualifies for assistance programs.
- Getting readyFloors and furniture protected, wall plate position marked level, wall opening located.
- The wall openingA single opening, with the slope the drain needs to flow outside.
- The outdoor unitSet on a stand raised above the snow, with the clearances the manufacturer requires.
- Lines, cable and drainConnected, insulated and protected. The opening is then sealed against water, cold air and insects.
- The electrical workA dedicated circuit and an accessible disconnect near the outdoor unit.
- Tests and start-upLeak test, vacuum, then start-up and a check of heating and cooling.
- The walkthroughRemote, modes, filters: we show you the essentials before we leave.
What would it look like at your place?
Two quick checks with real numbers: what heat costs, and what your current heaters add up to in BTU/h.
Conversion: 1 W = 3.412 BTU/h. An indication, not a load calculation: baseboards and furnaces are often stronger than the real need, and they can stay as backup. AirGreen confirms the capacity on site.
Four mistakes we do not make
Flip each card to see what we do instead.
Your own project, step by step
What to do, season by season
Three habits per season for this unit. They take a few minutes and prevent many calls.
- Clean the indoor unit's filters.
- Clear leaves and debris left on the outdoor unit by winter.
- Test cooling before the first hot days.
- Clean the filters more often when the unit runs a lot.
- Keep plants away from the outdoor unit.
- Check that no water drips from the indoor unit.
- Rake the leaves around the outdoor unit.
- Test heating before the first cold days.
- Book periodic maintenance before winter.
- Keep snow away from the stand and the front of the unit.
- Let the unit defrost: it is normal.
- Never hit the ice on the fins; call us if the unit stays iced up.
Is your home ready?
Check what applies at your place. A "no" is not a refusal: it is what we sort out during the estimate.
Four statements: true or false?
It all comes down to details you have just seen.
1. In heating mode, the outdoor unit can produce water.
During defrost cycles. That water must drain away without forming ice.
2. You pick the capacity with a simple square-footage rule.
Windows, insulation, orientation and how the room is used all count. Capacity is chosen on site.
3. A multi-zone connects several indoor heads to a single condenser.
One head per room, all on the same condenser. Each room keeps its own temperature.
4. The disconnect can sit behind the patio furniture.
It must stay accessible: it is what shuts the unit off for service.
0 / 4 right answers
What people ask us about this kind of work
Does a wall-mounted heat pump heat in winter?
Wall-mounted or multi-zone: how do I choose?
Where does the outdoor unit go?
Are there grants?
Do I need a permit?
How cold can it heat?
How much can I save?
How is the LogisVert assistance calculated?
Is it noisy?
The outdoor unit is covered in ice: is that normal?
Does AirGreen hold the required licences?
Is the estimate free?
No question matches. Write to us: we answer.
More jobs to see, near you
By town, by equipment or by region: browse more than 4,700 published projects.
Each dot: a town where AirGreen has published projects. The glowing dot: this job.
Every house has its constraints. We see them before we install.
The on-site estimate is free and the quote follows within 24 hours.
Text and photo: a real AirGreen Climatisation & Chauffage job. The diagrams are generic illustrations of the type of installation, not a survey of this job site. Sources of the added figures: airgreen.ca product pages (NEEP / AHRI performance), Hydro-Québec (Heat pumps page, LogisVert, read on 13 October 2026), Régie de l’énergie (rate D as of 1 April 2026).
