Electronic Thermostat HONEYWELL TH105PLUS/U | Montreal, Laval, Longueuil, South Shore & North Shore

In stock
SKU: TH105PLUS/U

From Monday to Friday, most homes follow a regular rhythm: getting up, leaving for work or school, coming home at the end of the day, going to bed.

3,500 Wmax. at 240 V
Programmablebuilt-in schedule
3 yearsmanufacturer warranty
Programmable
Get my installed price 514 316-2973

Quick facts

Model numberTH105PLUS/U
ProgrammableYes
Wi-FiNo
Touch screenNo
ENERGY STARNo
Warranty3 years

From Monday to Friday, most homes follow a regular rhythm: getting up, leaving for work or school, coming home at the end of the day, going to bed. On weekends, that rhythm changes. The Honeywell TH105PLUS/U is an electronic thermostat for electric baseboard heaters designed precisely around that reality. Its 5-2 programming separates weekdays from the weekend, with up to four periods per day: Wake, Leave, Return and Sleep. You set two schedules, not seven, and the thermostat applies them consistently all winter. It's an ideal first step into programming for households that have never used it.

5-2 programming, simple and effective

The TH105PLUS controls resistive electric heating, meaning baseboards, convectors and fan-forced heaters. It works on 120 V or 240 V circuits and accepts a load from 0.83 A to 14.6 A, which is 200 to 3,500 W at 240 V, or 100 to 1,750 W at 120 V. That range covers the vast majority of rooms in a house, from a small bedroom with a single baseboard to a family room with several.

TRIAC precision

Instead of a mechanical relay that clicks with every cycle, the TH105PLUS uses TRIAC switching. Heat is modulated silently, in short cycles, which keeps the temperature within ±0.15 °C of the setpoint, according to the manufacturer. In a bedroom, the absence of clicking is welcome; in a living area, the steady temperature is noticeable right away compared with an old bimetal thermostat.

Features that make life easier

The backlit LCD screen shows the room temperature, setpoint, time, day, mode and a heating power indicator that shows when the baseboards are working. The Early Start function begins heating a little before a period starts, so the target temperature is reached at the programmed time rather than after. Minimum and maximum temperature limits, along with the keypad lock, are useful in a rental unit, a child's bedroom or a commercial space. The thermostat needs no batteries.

Technical specifications

  • Stage: 1 heating, resistive electric heating
  • Equipment: electric baseboard heaters, convectors or fan-forced heaters (resistive loads only)
  • Voltage: 120/240 VAC, 60 Hz
  • Minimum load: 0.83 A (200 W at 240 V / 100 W at 120 V)
  • Maximum load: 14.6 A (3,500 W at 240 V / 1,750 W at 120 V)
  • TRIAC switching, ±0.15 °C accuracy
  • 5-2 programming: weekdays and weekend, up to 4 periods per day (Wake, Leave, Return, Sleep)
  • Display: backlit LCD (room temperature, setpoint, time and day, mode, power indicator)
  • Early Start function
  • Minimum and maximum temperature limits; keypad lock
  • Setting range: 5 to 30 °C (41 to 86 °F)
  • No batteries; connectivity: none
  • 6 in. tinned copper lead wires; UL and CSA approvals (CAN/CSA-C828-06)
  • Dimensions: 124 x 127 x 36 mm (4.9 x 5 x 1.4 in.)
  • Colour: white

Installation on a 120 V or 240 V circuit

An electronic thermostat for electric baseboard heaters connects directly to the heating circuit, at line voltage. So it's not a job to improvise. Our technicians turn off the breaker involved, confirm there is no voltage, identify the supply and load conductors, then connect the new control with the proper connectors. They then compare the actual load of the heaters on the circuit with the thermostat's capacity, to avoid any overload. Once power is restored, they check the display, the heating response and the setpoint.

Start-up and everyday use

At commissioning, our technicians set the time and day, then work out a first weekday and weekend schedule with you. For example, a comfortable temperature when you wake up, a lower setpoint during the workday, a return to comfort in the late afternoon and a moderate drop overnight. Saturday and Sunday follow a separate schedule, suited to spending more time at home. If one evening you need a bit more heat, just adjust the setpoint; the program then resumes as usual. Since the thermostat runs without batteries, there is no upkeep on that side.

Saving during the Québec winter

Heating makes up a large share of a Québec home's energy bill, especially from December to March. The simplest way to cut it without sacrificing comfort is to lower the temperature when the house is empty or everyone is asleep, then raise it just before you come home or wake up. A programmable thermostat does that every day, without forgetting. You only need to set the periods that match your routine once; the control then applies the schedule consistently, something nobody does as regularly by hand.

The TH105PLUS among baseboard thermostats

Our Honeywell selection for electric heating includes several programmable controls. The TH105PLUS/U stands out for its 5-2 programming, the simplest to set up, and its silent TRIAC switching. The TH106/U offers 7-day programming and a higher capacity, up to 4,000 W at 240 V, with Comfort, Economy and Vacation presets. The slimmer TH115-A models use a sound-dampened relay and offer a standby switch for the end of the season. If your schedule is the same from Monday to Friday, the TH105PLUS is often the most natural choice.

Maintenance and long-term use

An electronic thermostat for electric heating needs almost no maintenance. Wipe the housing with a dry cloth and never block the vents: the sensor needs to read the room air. Keep curtains, furniture and objects well away from the baseboards so air can circulate freely, which helps the control maintain a steady temperature. In spring, simply turn the setpoint down to the minimum or put the control on standby if it allows it. If the display stays blank or the room no longer heats, don't take the unit apart: turn off the breaker and contact us.

Why go through AirGreen

A thermostat can't be judged on its own: it depends on the equipment it controls, the existing wiring and the way you live in the house. That's why our advisors first ask simple questions about your heating system, the rooms that are hard to keep comfortable and your schedules. AirGreen Inc. is a family HVAC business founded in Montréal more than 15 years ago, licensed by the RBQ, serving Montréal, Laval, Longueuil, the North Shore and the South Shore. Our technicians work cleanly, explain what they're doing and leave the installation labelled to make any future maintenance easier. Our Boucherville showroom is open to those who prefer to see and handle the products before deciding.

Call on AirGreen for the sale and professional installation of this model in Montréal, Laval, Longueuil, the North Shore and the South Shore. Tell us the type of equipment to be controlled and the number of rooms involved, and we'll suggest a clear solution, installed by our own technicians.

01 · Key facts

Key facts: HONEYWELL TH105PLUS/U

Four things to know, then its ID card in twelve answers. “—” means the manufacturer does not publish it.

TypeLine-voltage thermostatHONEYWELL TH105PLUS/U
Forelectric baseboards, convectors or forced-air unitsDevices
Power120/240 VAC, 60 HzVoltage
Capacity0.83 AMinimum load
02 · Compatible?

Is the HONEYWELL TH105PLUS/U compatible with your heating?

Two steps, thirty seconds. The verdict takes your system and your wiring into account.

Full compatibility table

Heating systemVerdictWhy
Central heat pumpNoA central system is controlled in 24 V: see 24 V thermostats.
Dual energy (heat pump + furnace)NoDual energy is controlled in 24 V: see 24 V thermostats.
Electric furnaceNoA furnace is controlled in 24 V: see 24 V thermostats.
Gas or oil furnaceNoA furnace is controlled in 24 V: see 24 V thermostats.
Steam, gravity or hot waterNoA hydronic system needs a 24 V thermostat or a hydronic control.
Baseboards, convectors, radiant ceilingYesBaseboards, convectors and radiant ceilings, within the thermostat’s load range.
Fan-forced heaterYesThe spec sheet lists fan-forced heaters.
Electric floor heatingNoFloor heating needs a floor thermostat with a probe.
Wall or ducted mini-split heat pumpNoA wall heat pump is controlled by its own brand’s controller.
03 · Wiring

A thermostat that works on 120/240 V

Tap an element to see what it does. A working diagram, not a substitute for the manufacturer’s installation guide.

04 · Try it

Try the HONEYWELL TH105PLUS/U before you buy

Raise the setpoint, change the mode: see how it responds.

05 · Your savings

How much good programming can save you

Set up your typical week. The math follows the rule published by Natural Resources Canada.

06 · Winter and rebates

Winter, Rate Flex D and rebates: what this thermostat changes

With Hydro-Québec’s Rate Flex D, electricity costs less most of the winter and more during a few peak hours. A programmable thermostat does the work for you.

07 · Room by room

What each room costs

An interactive drawing of what this kind of control does day to day.

08 · Head to head

The HONEYWELL TH105PLUS/U or its closest sibling?

The most useful comparison: the model right next to it in our catalogue.

09 · The right choice

The right thermostat in three questions

If this model is not the right one for you, the page says so and shows you which one is.

10 · The system

Products that go with the HONEYWELL TH105PLUS/U

Parts named in its spec sheet that we sell and install.

11 · Installation

Installed and set up by our technicians, in five steps

What we do at your place, in order. The on-site estimate is free.

  1. 01LoadWe add up the heaters on the circuit and check the thermostat’s range.
  2. 02Shut-offBreaker shut off at the panel, 2- or 4-wire circuit identified.
  3. 03MountingWiring, mounting, power back on.
  4. 04TestHeating checked room by room.
  5. 05SettingsSchedule, connection and app if the model has them.
12 · Specifications

HONEYWELL TH105PLUS/U specifications

From the manufacturer’s sheet. Type a word: the list filters as you write.

GeneralStage1 heat, resistive electric heating
GeneralDeviceselectric baseboards, convectors or forced-air units (resistive loads only)
ElectricalVoltage120/240 VAC, 60 Hz
ElectricalMinimum load0.83 A (200 W at 240 V / 100 W at 120 V)
ElectricalMaximum load14.6 A (3500 W at 240 V / 1750 W at 120 V)
GeneralOtherTRIAC switching, ±0.15 °C accuracy
General5-2 programmingweekday and weekend, up to 4 periods per day (Wake, Leave, Return, Sleep)
Format and contentsDisplayBacklit LCD (room temperature, setpoint, time and day, mode, power indicator)
GeneralOtherEarly start (Early Start)
GeneralOtherMinimum and maximum temperature lock; keypad lock
GeneralAdjustment range5 to 30 °C (41 to 86 °F)
ConnectivityNo battery; connectivitynone
GeneralOther6 in. tinned copper lead wires; UL and CSA certified (CAN/CSA-C828-06)
Format and contentsDimensions124 x 127 x 36 mm (4.9 x 5 x 1.4 in.)
Format and contentsColourwhite
13 · Questions

Frequently asked questions about the HONEYWELL TH105PLUS/U

Short answers, no detours.

What does the HONEYWELL TH105PLUS/U work with?

According to the manufacturer’s sheet: electric baseboards, convectors or forced-air units (resistive loads only).

What load can it control?

Up to 3,500 W at 240 V (1,750 W at 120 V), per the manufacturer’s sheet.

Who installs it?

Our technicians: the circuit is shut off at the panel, the heater load is checked, then the thermostat is wired and tested.

Can it be controlled remotely?

Not directly: it has no built-in Wi-Fi.

What is the warranty?

3 years, per the manufacturer’s information.

Does AirGreen install it?

Yes. We sell and install this product in Montréal, Laval, Longueuil, the South Shore and the North Shore. The on-site estimate is free.

AirGreen · Montréal, Laval, Longueuil, South Shore, North Shore

Your thermostat, installed and set up by our technicians

We check your system and wiring, install the thermostat, connect it and program it with you. One visit, one installed price.

RBQ 5645-9605-01Ventilation, refrigeration and electrical
Free estimateon site, before any purchase
Quote in 24 hinstalled price, no surprises
Bouchervilleshowroom

Sources checked on October 5, 2026.

  • Manufacturer’s spec sheet for this product (summarized in the description and specifications above)
  • Natural Resources Canada, “Keeping the Heat In”, section 9 (modified September 29, 2025)
  • Hydro-Québec, electricity rates in effect April 1, 2026; Rate Flex D and Winter Credit Option pages (consulted October 5, 2026)
  • Énergir, smart thermostat grant (consulted October 5, 2026)

Savings shown are estimates; only Hydro-Québec and Énergir confirm a rate or a rebate.
