A single-stage furnace, an old dial thermostat and the wish to turn the heat down at night: 7-day or 5-1-1 schedule, on batteries (even millivolt) or a C wire.
Quick facts
A single-stage gas, oil or electric furnace that has answered to a dial thermostat for years: that is where a simple schedule changes daily life. The 80 Series 1F83C-11PR (EMERSON’s White-Rodgers line) lowers the setpoint at night and while you are at work, then brings it back up before you get home, as you program it, with no Wi-Fi or app.
The essentials of a programmable thermostat
- Single stage: 1 heat / 1 cool, for heat only, cool only or both.
- Schedule: 7-day or 5-1-1 (the default), 4 periods per day, or non-programmable mode.
- 24 V or millivolt: on batteries, with a system from mV to 30 VAC, or hardwired at 20 to 30 VAC with a C wire.
- 4.5 sq. in. screen: backlit and high-contrast.
- Keypad and setpoint: keypad lock and setpoint limits, within a 7 to 37 °C range.
- Tidy install: built-in level and a terminal block on the subbase.
Compatible furnaces and systems
It runs conventional gas, oil or electric furnaces, and a heat pump with no backup heat, at 1 heat / 1 cool. Dual fuel needs a backup stage that it does not have. Hot water and steam do not appear on its sheet. It is not suited to baseboards, convectors, radiant ceilings, fan-forced heaters, electric floor heating or wall and ducted heat pumps. In its 2025 cross-reference table, the brand lists the 1F83C-11PR to replace the 1F80-361, 1F87-361 and 1F80-0261.
Next to its neighbours
The EMERSON 80 Series 1F83C-11NP runs the same type of system without a schedule and takes a higher load: 1.5 A per terminal and 2.5 A total, against 1.0 A and 1.5 A here. The EMERSON 70 Series 1F75C-11PR also offers a 7-day or 5-1-1 schedule and also takes 1.5 A per terminal and 2.5 A total. Its sheet lists 2 AA batteries, a filter change reminder and continuous backlight as an option with a C wire; the 1F83C-11PR sheet lists the keypad lock and setpoint limits.
How AirGreen installs it
The technician identifies your system (24 V or millivolt, with or without air conditioning) and confirms its load does not exceed 1.0 A per terminal or 1.5 A total. They level the base, wire the terminal block, choose batteries or the C wire, then set the four periods of each day with you. The first step is a free in-home estimate.
Manufacturer document: 1F83C-11PR installation instructions (37-7758). Sold and installed by AirGreen. We serve Montréal, Laval, Longueuil, the North Shore and the South Shore.
Key facts: EMERSON 80 Series 1F83C-11PR
Four things to know, then its ID card in twelve answers. “—” means the manufacturer does not publish it.
Is the EMERSON 80 Series 1F83C-11PR compatible with your heating?
Two steps, thirty seconds. The verdict takes your system and your wiring into account.
Full compatibility table
The terminals behind the thermostat
Tap an element to see what it does. A working diagram, not a substitute for the manufacturer’s installation guide.
Try the EMERSON 80 Series 1F83C-11PR before you buy
Raise the setpoint, change the mode: see how it responds.
How much good programming can save you
Set up your typical week. The math follows the rule published by Natural Resources Canada.
Winter, Rate Flex D and rebates: what this thermostat changes
With Hydro-Québec’s Rate Flex D, electricity costs less most of the winter and more during a few peak hours. A programmable thermostat does the work for you.
The EMERSON 80 Series 1F83C-11PR or its closest sibling?
The most useful comparison: the model right next to it in our catalogue.
The right thermostat in three questions
If this model is not the right one for you, the page says so and shows you which one is.
Products that go with the EMERSON 80 Series 1F83C-11PR
Parts named in its spec sheet that we sell and install.
Installed and set up by our technicians, in five steps
What we do at your place, in order. The on-site estimate is free.
- 01InspectionEquipment, stages to control and existing wiring.
- 02C wireCommon wire added if the model needs it and it is missing.
- 03MountingWall base, terminal wiring, cover plate if needed.
- 04SettingsEquipment type, stages, dual energy and accessories.
- 05Start-upConnection, app, schedule and tests with you.
EMERSON 80 Series 1F83C-11PR specifications
From the manufacturer’s sheet. Type a word: the list filters as you write.
No line matches. Try another word.
Frequently asked questions about the EMERSON 80 Series 1F83C-11PR
Short answers, no detours.
What does the EMERSON 80 Series 1F83C-11PR work with?
According to the manufacturer’s sheet: conventional gas, oil or electric (millivolt and 24 V): heat only, cool only or both; heat pump with no backup heat.
Does it need a C wire?
Per the spec sheet, it can run on batteries; a common wire is still recommended when available.
Can it control electric baseboards?
No. It is a low-voltage (24 V) thermostat. 120/240 V baseboards need a line-voltage electronic thermostat.
Can it be controlled remotely?
Not directly: it has no built-in Wi-Fi.
What is the warranty?
5 years, per the manufacturer’s information.
Does AirGreen install it?
Yes. We sell and install this product in Montréal, Laval, Longueuil, the South Shore and the North Shore. The on-site estimate is free.
