Zephyr Series 23 Wall Mounted Heat Pump | 24,000 BTU R-32 | Montreal, Laval, Longueuil, South Shore & North Shore
Provincial Subsidy (LogisVert): 0$ (Updated: November 26, 2025)
Model Number (Interior): ZE-24CB22I
Model Number (Exterior): ZE-24CB22O
AHRI: 215414826
ENERGY STAR®: No
ENERGY STAR® (Cold Climate): No / No
# ENERGY STAR ID: -
Heating Capacity: -25°C
Cooling Capacity: 24,000 BTU
Gas (Freon): R-32
WiFi:
SEER2 (Seasonal Energy Efficiency Ratio)
1
19.5
30
HSPF2 (Heating Seasonal Performance Factor)
1
8.5
15
EER2 (Instant Cooling Efficiency)
1
10.6
20
Nominal Power: 24,000 BTU
Power at -8 °C: 21000 BTU
Power at -15 °C: 18500 BTU
Puissance à -20 °C (MAX) : 13000 BTU
COP at -8 °C (Heating energy efficiency)
1
2.51
4
COP à -15 °C (Rendement énergétique du chauffage)
1
1.9
4
COP à -20 °C (MAX)
1.12
4
Interior Dimensions (L x W x H): in
Shutter control - Vertical (Air direction): Auto
Shutter control - Horizontal (Air direction): Auto
Sound Pressure Level (Interior): dB(A)
External Dimensions (L x W x H): in
Piping: ft
Sound Pressure Level (Outdoor): dB(A)
Voltage: 220V
MCA (Minimum Circuit Ampacity): A
MOP (Maximum Overcurrent Protection): A
Warranty (Compressor - Parts - Labor): 10-10-0 years
Additional Warranty: Possible
