Electronic Thermostat HONEYWELL TH114-A-120S/U | Montreal, Laval, Longueuil, South Shore & North Shore
A small room heated by a convector or a 120 V forced-air heater also deserves precise control.
Quick facts
A small room heated by a convector or a 120 V forced-air heater also deserves precise control. The Honeywell TH114-A-120S/U is a non-programmable electronic thermostat designed for these circuits. It replaces a 120 V mechanical thermostat with a steadier, easier-to-read control, with a backlit screen and a heating power indicator. It is the choice for a bathroom, an entrance, a workshop, a heated sunroom or any space powered at 120 V where you simply want to set a temperature and stop thinking about it.
Electronic comfort for 120 V heaters
The TH114-A-120S controls electric baseboard heaters, radiant ceilings, convectors and forced-air heaters powered at 120 V. Its maximum load is 16.7 A resistive, or 2,000 W at 120 V. Its single-pole switching (SPST) goes through an epoxy-encapsulated relay, at 4 cycles per hour. The stated accuracy is ±0.5°C, with advanced control that reduces temperature swings.
Matching the circuit voltage
Choosing an electric heating thermostat always starts with the voltage. A 120 V heater must be controlled by a 120 V thermostat. Our technicians measure the actual circuit voltage, identify the connected heaters and add up their wattage before installing the TH114-A-120S/U. This check is all the more important in homes that have been through several renovations, where 120 V and 240 V circuits sometimes sit side by side without being clearly labelled at the panel.
Easy to read and simple
The backlit LCD screen displays the temperature in Celsius or Fahrenheit. The heating power indicator shows when the heater is powered. The ON/STANDBY switch puts the heating to rest for the summer. The thermostat needs no batteries and has no clock to set. It is compatible with the Aube CT240/CT241 telephone controller and carries UL and CSA approvals (CAN/CSA-C828-06).
Technical specifications
- Stage: 1 heating, resistive electric heating
- Heaters: electric baseboard heaters, radiant ceilings, convectors or forced-air heaters
- Voltage: 120 VAC, 50/60 Hz
- Maximum load: 16.7 A resistive (2,000 W at 120 V)
- Single-pole switching (SPST); epoxy-encapsulated relay; 4 cycles per hour
- Non-programmable
- Display: backlit LCD; heating power indicator; Celsius or Fahrenheit
- ON/STANDBY switch for the end of the season
- Accuracy: ±0.5°C
- Setting range: 5 to 30°C (40 to 86°F)
- Compatible with the Aube CT240/CT241 telephone controller
- UL/CSA approvals (CAN/CSA-C828-06); hardwired, no batteries
- Connectivity: none
- Dimensions: 124 x 70 x 23 mm (4.9 x 2.8 x 0.9 in.)
- Colour: white
Safe installation by AirGreen
On electric heating circuits, safety comes first. Before touching the box, the technician switches off the breaker, checks with a meter that no voltage is present and locates the wires that feed the control and those that run to the baseboard heaters or convectors. The technician adds up the wattage of the connected heaters to make sure it stays within the thermostat's maximum load. The new model is then mounted securely, the connections are tightened and insulated, and we restore power for a heating test. You have nothing to handle: we leave the control set and working.
A control you can forget about
In rooms where you spend little time, such as an entrance or a workshop, the ideal thermostat is one you set once and for all. The TH114-A-120S/U holds the setpoint consistently and needs no attention after a power failure. In a bathroom, a comfortable setpoint at shower time, then slightly lower the rest of the time, is enough for most families. The slim white housing blends discreetly into the wall, and the backlit display stays readable even in a windowless room.
Managing heat room by room
With one thermostat per room, each zone of the house can be set according to how it is used. This is one of the great advantages of zoned heating: the family room can stay comfortable while the guest room or an unoccupied office stays cooler. A non-programmable control simply means adjusting the setpoint by hand when your needs change. During the cold months, this room-by-room management is an effective, hassle-free way to limit electricity use.
Choosing between the TH114-A versions
The TH114-A-120S/U is the 120 V version of the non-programmable TH114-A line. For 240 V circuits, the TH114-A-240S-B/U (single-pole, 4,000 W) and the TH114-A-240D-B/U (double-pole, 3,600 W) take over. If you want to program the 120 V room on a weekly schedule, the TH115-A-120S/U offers the same housing with 7-day programming. The TH114-A-120S/U remains the simplest choice for a 120 V heater you want to control precisely, without a schedule.
Maintaining your electric heating
The electronic thermostat has no moving parts to replace, which makes it very durable. Maintenance is limited to keeping the housing clean and unobstructed. The heaters it controls do deserve a little attention, though: dusting baseboard heaters and convectors before the cold season, checking that nothing blocks the air outlet of unit heaters, and a visual check of older units. If a baseboard heater gives off an unusual smell or shows signs of overheating, switch off its circuit and have it inspected.
The know-how of a family business
AirGreen grew out of a family of tradespeople and has kept their instincts: do the job right the first time, explain clearly and stay reachable after the installation. For more than 15 years, we have been installing and servicing heating, air conditioning and ventilation equipment in homes and businesses in Montréal, Laval, Longueuil, the North Shore and the South Shore. Our RBQ licence governs our work, and our team knows furnaces and heat pumps as well as electric baseboard heaters and floor heating. When we replace a thermostat, we take the opportunity to look over the equipment it controls and point out anything that deserves your attention. Our showroom in Boucherville welcomes you if you would like to compare several models.
To move forward, write to us or call AirGreen. Our advisors confirm compatibility with your installation, then our technicians install and commission the thermostat in your home, in Montréal, Laval, Longueuil, the North Shore or the South Shore.
Key facts: HONEYWELL TH114-A-120S/U
Four things to know, then its ID card in twelve answers. “—” means the manufacturer does not publish it.
Is the HONEYWELL TH114-A-120S/U compatible with your heating?
Two steps, thirty seconds. The verdict takes your system and your wiring into account.
Full compatibility table
A thermostat that works on 120/240 V
Tap an element to see what it does. A working diagram, not a substitute for the manufacturer’s installation guide.
Try the HONEYWELL TH114-A-120S/U before you buy
Raise the setpoint, change the mode: see how it responds.
Winter, Rate Flex D and rebates: what this thermostat changes
With Hydro-Québec’s Rate Flex D, electricity costs less most of the winter and more during a few peak hours. Turning the setpoint down a few degrees during those hours is what counts.
What each room costs
An interactive drawing of what this kind of control does day to day.
The HONEYWELL TH114-A-120S/U or its closest sibling?
The most useful comparison: the model right next to it in our catalogue.
The right thermostat in three questions
If this model is not the right one for you, the page says so and shows you which one is.
Products that go with the HONEYWELL TH114-A-120S/U
Parts named in its spec sheet that we sell and install.
Installed and set up by our technicians, in five steps
What we do at your place, in order. The on-site estimate is free.
- 01LoadWe add up the heaters on the circuit and check the thermostat’s range.
- 02Shut-offBreaker shut off at the panel, 2- or 4-wire circuit identified.
- 03MountingWiring, mounting, power back on.
- 04TestHeating checked room by room.
- 05SettingsSchedule, connection and app if the model has them.
HONEYWELL TH114-A-120S/U specifications
From the manufacturer’s sheet. Type a word: the list filters as you write.
No line matches. Try another word.
Frequently asked questions about the HONEYWELL TH114-A-120S/U
Short answers, no detours.
What does the HONEYWELL TH114-A-120S/U work with?
According to the manufacturer’s sheet: electric baseboards, radiant ceilings, convectors or forced-air units.
Who installs it?
Our technicians: the circuit is shut off at the panel, the heater load is checked, then the thermostat is wired and tested.
Can it be controlled remotely?
Not directly: it has no built-in Wi-Fi.
What is the warranty?
3 years, per the manufacturer’s information.
Does AirGreen install it?
Yes. We sell and install this product in Montréal, Laval, Longueuil, the South Shore and the North Shore. The on-site estimate is free.
