Electronic Thermostat HONEYWELL TH141HC-28-B/U | Montreal, Laval, Longueuil, South Shore & North Shore
A home equipped with a furnace and a central air conditioner needs a control that handles both seasons without you having to think about it.
Quick facts
A home equipped with a furnace and a central air conditioner needs a control that handles both seasons without you having to think about it. The Honeywell TH141HC-28-B/U, from the Aube line, is a 7-day programmable electronic thermostat for 24 V conventional heating and cooling systems. Its automatic changeover between heating and cooling lets it switch from one mode to the other based on temperature, which is especially useful in spring and fall, when warm days and cool nights follow one another. It runs on batteries and also controls the fan.
Programmed heating and cooling all year round
The TH141HC controls one heating stage and one cooling stage on a 24 VAC conventional system, with a 1.5 A capacity for the heating, cooling and fan outputs. It is powered by two AA alkaline batteries, with a low-battery indicator that warns you 60 days ahead. The LCD display shows the temperature in 0.1-degree increments.
Automatic changeover
With a manual changeover thermostat, you have to flip the selector from one mode to the other at every change of season, and sometimes several times a week in May or September. The TH141HC takes care of it automatically. The setpoint ranges are separate: 5 to 30 °C in heating and 15 to 40 °C in cooling. Fan control, in the ON or AUTO position, lets air circulate continuously or only during cycles.
Suitable cycles
Heating cycles are selectable to match your equipment, which contributes to smooth operation and consistent comfort. Programming is done with the faceplate removed from its base, a practical method that lets you set the schedule sitting down rather than standing in front of the wall. A remote input also accepts the CT240 telephone controller.
Technical specifications
- Stages: 1 heating / 1 cooling
- System: low-voltage (24 VAC) conventional heating and cooling
- Power: 24 VAC; 2 AA alkaline batteries; 1.5 A (heating, cooling, fan)
- 7-day programmable
- Automatic heating/cooling changeover
- ON/AUTO fan control
- Selectable heating cycles
- Setting range: 5 to 30 °C in heating, 15 to 40 °C in cooling
- Display: LCD, temperature in 0.1-degree increments
- Programming with the faceplate removed from the base
- Low-battery indicator (60-day advance warning)
- Remote input for CT240 telephone controller
- Connectivity: none
- Dimensions: 127 x 97 x 26 mm (4.9 x 3.8 x 1 in.)
- Colour: white
Installation by our technicians
On a low-voltage system, the replacement starts by cutting power to the unit at the disconnect switch or the panel. Our technicians identify each conductor before removing the old thermostat, check the voltage at the 24 V transformer, then connect the new base according to your equipment's terminals. The control is then configured for the system type, and we run a full heating cycle, and a cooling cycle if applicable, to make sure everything responds normally. We also use the visit to check the location: a thermostat placed near an exterior door, a supply register or a sunny window reads a temperature that doesn't represent the room.
A year with the TH141HC
In winter, programming lowers the heating setpoint at night and while you're away, then raises it before you return. In summer, it lets the house stay a bit warmer during the workday and cools it before you arrive, which limits the air conditioner's run time. In between, automatic changeover means you don't have to step in. During installation, our technicians set up a schedule for each season with you and show you how to temporarily override the program for a special evening.
Making good use of programming in winter
Many homeowners buy a programmable thermostat and then leave it in manual mode. That's a shame, because the schedule is exactly the tool that turns the control into a source of savings. For a home occupied in the evening and on weekends, four periods per day are plenty: wake, leave, return and sleep. During extreme cold, it's better to avoid deep setbacks, which force the heating to make up a large gap. A moderate, regular setback gives the best balance between comfort and consumption.
The TH141HC compared with the other controls in our selection
In the battery-powered Aube line, the TH141HC-28-B/U is the only model that controls cooling. The TH140-28-01-B/U keeps 7-day programming but is limited to heating, from millivolt to 240 V. The TH135-01-B/U is a compact non-programmable control for heating only. For a 24 V conventional system with cooling that doesn't need programming, The Round T87N1018/U is a simple alternative. If your system includes a heat pump with backup heat, a FocusPRO N100 will be more appropriate.
Maintenance tips
The thermostat itself only needs occasional dusting. Most of the maintenance involves the equipment it controls: filters replaced according to the manufacturer's recommendations, annual inspection of the furnace or boiler, cleaning the heat pump and clearing the outdoor unit in winter. These steps protect your system's performance and let the thermostat do its job properly. AirGreen services furnaces and heat pumps throughout the region, so you can keep everything with the same team.
AirGreen by your side, before and after installation
Replacing a thermostat seems simple, but the wrong model or sloppy wiring later costs you in discomfort and service calls. AirGreen Inc., a family heating and air conditioning business founded in Montréal more than 15 years ago, makes sure every control it installs suits its equipment and its circuit. Under AirGreen's RBQ licence, our technicians work in houses, condos, plexes and commercial spaces in Montréal, Laval, Longueuil, the North Shore and the South Shore. We keep a record of what was installed at your place, which simplifies any future work, whether adding a zone, replacing a unit or reviewing your settings. Our Boucherville showroom also lets you see several controls side by side.
Contact AirGreen for the purchase and professional installation of this thermostat in Montréal, Laval, Longueuil, the North Shore or the South Shore. Describe your current system, or send us a photo of the existing thermostat and its wiring: we'll confirm compatibility and schedule a visit at your convenience.
Key facts: HONEYWELL TH141HC-28-B/U
Four things to know, then its ID card in twelve answers. “—” means the manufacturer does not publish it.
Is the HONEYWELL TH141HC-28-B/U compatible with your heating?
Two steps, thirty seconds. The verdict takes your system and your wiring into account.
Full compatibility table
The terminals behind the thermostat
Tap an element to see what it does. A working diagram, not a substitute for the manufacturer’s installation guide.
Try the HONEYWELL TH141HC-28-B/U before you buy
Raise the setpoint, change the mode: see how it responds.
How much good programming can save you
Set up your typical week. The math follows the rule published by Natural Resources Canada.
Winter, Rate Flex D and rebates: what this thermostat changes
With Hydro-Québec’s Rate Flex D, electricity costs less most of the winter and more during a few peak hours. A programmable thermostat does the work for you.
The HONEYWELL TH141HC-28-B/U or its closest sibling?
The most useful comparison: the model right next to it in our catalogue.
The right thermostat in three questions
If this model is not the right one for you, the page says so and shows you which one is.
Products that go with the HONEYWELL TH141HC-28-B/U
Parts named in its spec sheet that we sell and install.
Installed and set up by our technicians, in five steps
What we do at your place, in order. The on-site estimate is free.
- 01InspectionEquipment, stages to control and existing wiring.
- 02C wireCommon wire added if the model needs it and it is missing.
- 03MountingWall base, terminal wiring, cover plate if needed.
- 04SettingsEquipment type, stages, dual energy and accessories.
- 05Start-upConnection, app, schedule and tests with you.
HONEYWELL TH141HC-28-B/U specifications
From the manufacturer’s sheet. Type a word: the list filters as you write.
No line matches. Try another word.
Frequently asked questions about the HONEYWELL TH141HC-28-B/U
Short answers, no detours.
Does it need a C wire?
Per the spec sheet, it can run on batteries; a common wire is still recommended when available.
Can it control electric baseboards?
No. It is a low-voltage (24 V) thermostat. 120/240 V baseboards need a line-voltage electronic thermostat.
Can it be controlled remotely?
Not directly: it has no built-in Wi-Fi.
What is the warranty?
3 years, per the manufacturer’s information.
Does AirGreen install it?
Yes. We sell and install this product in Montréal, Laval, Longueuil, the South Shore and the North Shore. The on-site estimate is free.
