Electronic Thermostat HONEYWELL TH450/U | Montreal, Laval, Longueuil, South Shore & North Shore
Large electrically heated rooms pose a particular challenge: several baseboards on the same circuit, a heavy load and a need for even comfort over a large area.
Quick facts
Large electrically heated rooms pose a particular challenge: several baseboards on the same circuit, a heavy load and a need for even comfort over a large area. The Honeywell TH450/U meets that need. This non-programmable electronic thermostat accepts up to 16.7 A, or 4,000 W at 240 V, while offering the silent TRIAC switching and the ±0.15 °C precision usually associated with models meant for small rooms. Open-concept living room, finished basement, family room or commercial space: the TH450 delivers steady, silent heat where the load is heaviest.
High capacity and silent switching
The TH450 controls electric baseboard heaters, radiant ceilings, convectors and fan-forced heaters on 120 V, 208 V or 240 V circuits. Its load range runs from 1.25 A to 16.7 A, with a maximum capacity of 2,000 W at 120 V, 3,465 W at 208 V and 4,000 W at 240 V. It is UL approved. Its thermistor sensor reads the room temperature, and its electronic switching modulates the heat without any clicking.
The right cycle for each type of heater
The cycle can be set to 15 seconds or 5 minutes. The short cycle suits baseboards, which it powers in closely spaced pulses for a very steady temperature. The 5-minute cycle is reserved for fan-forced heaters, whose fan needs longer cycles. When the same room combines several types of heaters, our technicians examine the circuit to determine the right setting, or suggest separating the controls.
Locks for shared spaces
The TH450 offers minimum and maximum setpoint limits, as well as a keypad lock. In a commercial space, a meeting room, a rental unit or a playroom, these functions prevent unwanted changes and protect the electricity bill. The 0.98 sq in. backlit screen stays readable at all times, and the thermostat runs without batteries.
Technical specifications
- Stage: 1 heating
- Equipment: electric baseboards, radiant ceilings, convectors, fan-forced heaters
- Voltage: 120 / 208 / 240 VAC, 60 Hz
- Load: 1.25 to 16.7 A (up to 2,000 W at 120 V, 3,465 W at 208 V, 4,000 W at 240 V)
- Silent TRIAC switching
- Selectable cycle: 15 s or 5 min (fan-forced heaters)
- Non-programmable
- Display: 0.98 sq in. backlit
- Minimum and maximum setpoint limits; keypad lock
- Accuracy: ±0.15 °C; setting range: 5 to 30 °C
- Sensor: thermistor
- No batteries; UL approval; connectivity: none
- Dimensions: 127 x 127 x 36 mm (5.0 x 5.0 x 1.42 in.)
- Colour: white
Professional installation
Connecting a line voltage control requires turning off the right breaker, checking that no current is present and respecting the thermostat's capacity. That's exactly what our technicians do on every visit. They check the circuit voltage, calculate the load of the connected heaters, mount the new base level, then make the connections and the final test. If the wall box is too narrow, damaged or poorly secured, they fix it before closing up. The result is a clean, safe installation ready for winter.
Use and settings
Once in place, the TH450 works like any non-programmable thermostat: you choose the temperature, and the control maintains it. In a large room, the stability provided by TRIAC switching is especially noticeable, because the differences between areas near and far from the baseboards are less pronounced when power is finely modulated. At commissioning, we set the cycle type, the setpoint limits if you wish and, if needed, the keypad lock. The square 127 x 127 mm housing covers the marks left by an old thermostat well.
Comfort to the right degree
During the Québec winter, the difference between a comfortable house and an overheated one often comes down to one or two degrees. A thermostat that reads the temperature accurately and holds it steady avoids the overshoots that drive up the bill. To go further, adopt a simple routine: a normal setpoint when you're home and a reduced setpoint at night or while you're away. This manual adjustment takes a few seconds and gives concrete results over a full season.
The TH450 and related options
The TH450/U is the high-capacity version of the non-programmable TRIAC control. The TH401/U takes the same approach for more modest loads, up to 2,500 W at 240 V, without a keypad lock. For a large room that would follow a schedule, the TH106/U combines TRIAC switching, a 4,000 W capacity at 240 V and 7-day programming. If you prefer a slimmer housing with a sound-dampened relay, the non-programmable TH114-A line is also available. Our advisors guide you based on the circuit load and how the room is used.
Durability and safety
Electronic controls are designed to run for many years without attention. To keep them in good condition, avoid direct moisture, spray cleaners and impacts. Never use a thermostat to control a load greater than its capacity, even temporarily, for example by adding a baseboard to an existing circuit without checking. If you're planning renovations that affect the heating, talk to our technicians: they'll check that the existing control is still suitable.
AirGreen by your side, before and after installation
Replacing a thermostat seems simple, but the wrong model or sloppy wiring later costs you in discomfort and service calls. AirGreen Inc., a family heating and air conditioning business founded in Montréal more than 15 years ago, makes sure every control it installs suits its equipment and its circuit. Under AirGreen's RBQ licence, our technicians work in houses, condos, plexes and commercial spaces in Montréal, Laval, Longueuil, the North Shore and the South Shore. We keep a record of what was installed at your place, which simplifies any future work, whether adding a zone, replacing a unit or reviewing your settings. Our Boucherville showroom also lets you see several controls side by side.
Contact AirGreen for the purchase and professional installation of this thermostat in Montréal, Laval, Longueuil, the North Shore or the South Shore. Describe your current system, or send us a photo of the existing thermostat and its wiring: we'll confirm compatibility and schedule a visit at your convenience.
Key facts: HONEYWELL TH450/U
Four things to know, then its ID card in twelve answers. “—” means the manufacturer does not publish it.
Is the HONEYWELL TH450/U compatible with your heating?
Two steps, thirty seconds. The verdict takes your system and your wiring into account.
Full compatibility table
A thermostat that works on 120/240 V
Tap an element to see what it does. A working diagram, not a substitute for the manufacturer’s installation guide.
Try the HONEYWELL TH450/U before you buy
Raise the setpoint, change the mode: see how it responds.
Winter, Rate Flex D and rebates: what this thermostat changes
With Hydro-Québec’s Rate Flex D, electricity costs less most of the winter and more during a few peak hours. Turning the setpoint down a few degrees during those hours is what counts.
What each room costs
An interactive drawing of what this kind of control does day to day.
The HONEYWELL TH450/U or its closest sibling?
The most useful comparison: the model right next to it in our catalogue.
The right thermostat in three questions
If this model is not the right one for you, the page says so and shows you which one is.
Products that go with the HONEYWELL TH450/U
Parts named in its spec sheet that we sell and install.
Installed and set up by our technicians, in five steps
What we do at your place, in order. The on-site estimate is free.
- 01LoadWe add up the heaters on the circuit and check the thermostat’s range.
- 02Shut-offBreaker shut off at the panel, 2- or 4-wire circuit identified.
- 03MountingWiring, mounting, power back on.
- 04TestHeating checked room by room.
- 05SettingsSchedule, connection and app if the model has them.
HONEYWELL TH450/U specifications
From the manufacturer’s sheet. Type a word: the list filters as you write.
No line matches. Try another word.
Frequently asked questions about the HONEYWELL TH450/U
Short answers, no detours.
What does the HONEYWELL TH450/U work with?
According to the manufacturer’s sheet: electric baseboards, radiant ceilings, convectors, forced-air units.
What load can it control?
Up to 4,000 W at 240 V (2,000 W at 120 V), per the manufacturer’s sheet.
Who installs it?
Our technicians: the circuit is shut off at the panel, the heater load is checked, then the thermostat is wired and tested.
Can it be controlled remotely?
Not directly: it has no built-in Wi-Fi.
What is the warranty?
3 years, per the manufacturer’s information.
Does AirGreen install it?
Yes. We sell and install this product in Montréal, Laval, Longueuil, the South Shore and the North Shore. The on-site estimate is free.
No question matches. Call us at 514 316-2973.
Your thermostat, installed and set up by our technicians
We check your system and wiring, install the thermostat, connect it and program it with you. One visit, one installed price.
