EMERSON Blue Series 2" Easy Set 1F86EZ-0251 Thermostat | Montreal, Laval, Longueuil, South Shore & North Shore

In stock
SKU: 1F86EZ-0251

One touch on the way out, another at bedtime: the 1F86EZ-0251 stores your Home, Sleep and Away settings, with no schedule to program.

Home, Sleep, Awaythree keys, no schedule
2 AA batteriesincluded, or hardwired
5 yearsmanufacturer warranty
Get my installed price 514 316-2973

Quick facts

Model number1F86EZ-0251
ProgrammableNo
Wi-FiNo
Touch screenNo
ENERGY STARNo
Warranty5 years

You once had a programmable thermostat and never got around to entering the schedule. With the Blue Series 2" Easy Set 1F86EZ-0251 (the White-Rodgers line from EMERSON) there is nothing to program: you store your Home, Sleep and Away settings, then switch between them with a single touch. One press on the way out in the morning, another at bedtime.

Three buttons instead of a schedule

  • Home, Sleep, Away: three one-touch settings.
  • Sleep timer: built in, alongside the three settings.
  • Non-programmable: no schedule to set up or keep current.
  • Large-character screen: 2 sq. in. blue backlit LCD, with display recalibration.
  • Compressor and peaks: short-cycle protection for the compressor, and Cool Savings during cooling peaks.
  • Batteries or C wire: 2 AA batteries included, or hardwired at 20 to 30 VAC.

Which systems

The 1F86EZ-0251 can be set up for a single-stage system or a heat pump. It controls one heating stage and one cooling stage on a gas, oil or electric furnace, or on a single-stage heat pump without backup heat, and it handles millivolt systems when running on batteries. No dual fuel, since there is no backup stage, and no baseboards, electric floor heating, fan-forced heaters or wall or ducted heat pumps. As for hot water or steam systems, the 1F86EZ-0251 sheet does not name them.

Its two closest siblings

The EMERSON Blue Series 2" 1F86-0244 is the same size and controls the same systems; its sheet simply lists it as non-programmable, with no mention of Home, Sleep or Away settings. For a heat pump with backup heat (2 heating stages), the EMERSON Blue Series 2" Easy Set 1F89EZ-0251 offers the same settings.

Set up by AirGreen

The 1F86EZ-0251 runs on 2 AA batteries or hardwired; we choose based on the wires already in the wall. We set it to single-stage or heat pump to match your equipment, then store your three settings with you so each button is ready from the first evening. A free in-home estimate comes before the installation.

Manufacturer document: White-Rodgers and Sensi manuals page. Sold and installed by AirGreen. We serve Montréal, Laval, Longueuil, the North Shore and the South Shore.

01 · Key facts

Key facts: EMERSON Blue Series 2" Easy Set 1F86EZ-0251

Four things to know, then its ID card in twelve answers. “—” means the manufacturer does not publish it.

Type24 V thermostatEMERSON Blue Series 2" Easy Set 1F86EZ-0251
Forsingle-stage systemsSystems
Powerbatteries: mV to 30 VAC or DCPower supply
ConnectionnoneConnectivity
02 · Compatible?

Is the EMERSON Blue Series 2" Easy Set 1F86EZ-0251 compatible with your heating?

Two steps, thirty seconds. The verdict takes your system and your wiring into account.

Full compatibility table

Heating systemVerdictWhy
Central heat pumpYesSingle-stage heat pump without backup heat only (1H/1C).
Dual energy (heat pump + furnace)NoOne heating stage only: dual energy needs a backup stage.
Electric furnaceYes24 V control of the furnace.
Gas or oil furnaceYes24 V control of the furnace; the thermostat does not touch the fuel supply.
Steam, gravity or hot waterTo confirmThis model’s sheet does not name hot water or steam systems.
Baseboards, convectors, radiant ceilingNoA baseboard runs on 120/240 V: it needs a line-voltage electronic thermostat.
Fan-forced heaterNoA fan-forced heater needs a line-voltage thermostat rated for fans.
Electric floor heatingNoElectric floor heating needs a floor thermostat with a probe.
Wall or ducted mini-split heat pumpNoA wall heat pump is controlled by its own brand’s controller or a compatible Wi-Fi module.
03 · Wiring

The terminals behind the thermostat

Tap an element to see what it does. A working diagram, not a substitute for the manufacturer’s installation guide.

04 · Try it

Try the EMERSON Blue Series 2" Easy Set 1F86EZ-0251 before you buy

Raise the setpoint, change the mode: see how it responds.

05 · Winter and rebates

Winter, Rate Flex D and rebates: what this thermostat changes

With Hydro-Québec’s Rate Flex D, electricity costs less most of the winter and more during a few peak hours. Turning the setpoint down a few degrees during those hours is what counts.

06 · Head to head

The EMERSON Blue Series 2" Easy Set 1F86EZ-0251 or its closest sibling?

The most useful comparison: the model right next to it in our catalogue.

07 · The right choice

The right thermostat in three questions

If this model is not the right one for you, the page says so and shows you which one is.

08 · Installation

Installed and set up by our technicians, in five steps

What we do at your place, in order. The on-site estimate is free.

  1. 01InspectionEquipment, stages to control and existing wiring.
  2. 02C wireCommon wire added if the model needs it and it is missing.
  3. 03MountingWall base, terminal wiring, cover plate if needed.
  4. 04SettingsEquipment type, stages, dual energy and accessories.
  5. 05Start-upConnection, app, schedule and tests with you.
09 · Specifications

EMERSON Blue Series 2" Easy Set 1F86EZ-0251 specifications

From the manufacturer’s sheet. Type a word: the list filters as you write.

GeneralStages1 heat / 1 cool; single stage or heat pump
GeneralSystemssingle-stage systems (gas, oil, electric, millivolt on batteries); single-stage heat pump with no backup heat
GeneralProgrammingEasy Set, non-programmable: one-touch Home, Sleep and Away settings; sleep timer
ElectricalPower supplybatteries: mV to 30 VAC or DC; hardwired: 20 to 30 VAC; 2 AA batteries included
ElectricalTerminalsR, C, O/B, W, Y, G
GeneralSetpoint range7 to 32 °C (45 to 90 °F)
Format and contentsDisplay2 sq. in. blue backlit LCD, large characters
GeneralFeaturesCool Savings (cooling peak), display recalibration, compressor short-cycle protection
ConnectivityConnectivitynone (no Wi-Fi)
Format and contentsDimensions3-3/4 in. (H) x 4-3/4 in. (W) x 1-1/2 in. (D)
Format and contentsColourwhite
GeneralManufacturer instructions37-7201 (White-Rodgers)
10 · Questions

Frequently asked questions about the EMERSON Blue Series 2" Easy Set 1F86EZ-0251

Short answers, no detours.

What does the EMERSON Blue Series 2" Easy Set 1F86EZ-0251 work with?

According to the manufacturer’s sheet: single-stage systems (gas, oil, electric, millivolt on batteries); single-stage heat pump with no backup heat.

Does it need a C wire?

Per the spec sheet, it can run on batteries; a common wire is still recommended when available.

Can it control electric baseboards?

No. It is a low-voltage (24 V) thermostat. 120/240 V baseboards need a line-voltage electronic thermostat.

Can it be controlled remotely?

Not directly: it has no built-in Wi-Fi.

Does AirGreen install it?

Yes. We sell and install this product in Montréal, Laval, Longueuil, the South Shore and the North Shore. The on-site estimate is free.

AirGreen · Montréal, Laval, Longueuil, South Shore, North Shore

Your thermostat, installed and set up by our technicians

We check your system and wiring, install the thermostat, connect it and program it with you. One visit, one installed price.

RBQ 5645-9605-01Ventilation, refrigeration and electrical
Free estimateon site, before any purchase
Quote in 24 hinstalled price, no surprises
Bouchervilleshowroom

Sources checked on October 5, 2026.

  • Manufacturer’s spec sheet for this product (summarized in the description and specifications above)
  • Natural Resources Canada, “Keeping the Heat In”, section 9 (modified September 29, 2025)
  • Hydro-Québec, electricity rates in effect April 1, 2026; Rate Flex D and Winter Credit Option pages (consulted October 5, 2026)
  • Énergir, smart thermostat grant (consulted October 5, 2026)

Savings shown are estimates; only Hydro-Québec and Énergir confirm a rate or a rebate.
