Wall heat pumps: what installation limits does each manufacturer publish? Four models compared

Wall heat pumps · Installation · 12,000 BTU/h

Before installing: the limits each manufacturer writes down

This article used to ask why an installer turns down some installations. The answer is often in the manufacturer's documents: piping length, height difference between the two units, pre-charged length, electrical protection, operating range. Beyond those limits, the installation leaves the conditions the manufacturer describes. Here are those limits for four 12,000 BTU wall heat pumps that AirGreen sells, in alphabetical order of brand, with no ranking.

12,000 BTU/h nominal4 AHRI certificatesENERGY STAR cold climate: 4 of 4 (NEEP)Data verified November 17, 2026
HITACHI airHome 800 12 000 BTU (AirGreen image)
HITACHI

airHome 800

RAK-XJ12PHAA / RAC-XJ12WHAA
AHRI 215911631 · NEEP 484774

NEEP series “airHome 800”.

See the product page
KINGHOME POLARIS R32 12 000 BTU (AirGreen image)
KINGHOME

POLARIS R32

KWP12R32C3I / KWP12R32C3O
AHRI 218451122 · NEEP 426104

NEEP series “Glovia”.

See the product page
SAMSUNG WindFree MaxHeat R32 12 000 BTU (AirGreen image)
SAMSUNG

WindFree MaxHeat R32

AR12DXDABWKN / AR12DXDACWKX
AHRI 215399291 · NEEP 389387

NEEP series “WindFree - Max heat (RAC)”.

See the product page
TCL ULTIMATE 25 12 000 BTU (AirGreen image)
TCL

ULTIMATE 25

H12SUH25XGE / H12SUH25XGC
AHRI 216506201 · NEEP 382523

NEEP series “EXHEAT”.

See the product page
50 to 131 ftmaximum published piping length, depending on the model
24.6 to 49 ftfactory pre-charged length, before any refrigerant is added
33 to 65.6 ftmaximum published height difference between the units, when published
−30 °Clower limit of the announced heating range, for all four
Estimated operating cost

What the electricity costs, in dollars, winter and summer

Installation limits decide where the unit can go; its certified efficiencies, what it will cost afterwards. Here is what they come to in dollars for the same 12,000 BTU/h zone in Montréal, at Hydro-Québec's Rate D, taxes included, with the same method as on all our comparison pages. Electric baseboards are the reference; choose two models, and the table of all four follows the same settings.

See in detail:

All four, same method, same settings

ModelWinter · heatingSummer · coolingYearLess than baseboards, in winter

Heating: certificate HSPF2 Region V; cooling: SEER2. Same 12,000 BTU/h nominal size for all four. The bars share one scale.

How this amount is calculated
  1. Heat needed over the winter. A zone whose heat loss reaches 12,000 BTU/h ( kW) at −23.1 °C, Montréal's design temperature: kW × 24 h × 4,167 degree-days ÷ (18 − (−23.1)) = kWh of heat for round-the-clock heating, all winter. Heating degree-days (18 °C base) and design temperature: Natural Resources Canada, HOT2000 climate data, Montréal Intl station. With fewer hours a day (“Heating” slider), the heat is reduced in the same proportion, for the heat pump as for the baseboards: this simplification ignores the recovery after a temperature setback.
  2. Electricity for heating. Heat pump: heat × 3.412 ÷ HSPF2 Region V, the AHRI certificate value published by NEEP. Region V is the coldest in the standard, and its calculation includes the electric backup planned for when the heat pump is no longer enough. Electric baseboards: 1 kWh of electricity for 1 kWh of heat.
  3. Electricity for cooling. 12,000 BTU/h ÷ SEER2 × hours a day × 60 days ÷ 1,000: the method of Hydro-Québec's air-conditioning calculator, with the seasonal SEER2 efficiency from the AHRI certificate. The number of hours is a scenario, adjustable above from 1 to 24 h. At 24 h, the calculation assumes rated capacity all day: that is a maximum, since a variable-speed unit slows down once the room reaches the set temperature.
  4. Price. Hydro-Québec Rate D in effect April 1, 2026: 7.065¢ per kWh up to 40 kWh a day, 11.142¢ above that; the average price, 9.104¢, is the one Hydro-Québec's calculators use. GST and QST included. Network access charges, the same with or without a heat pump, are not counted.

AirGreen method v1.1, November 9, 2026. An estimate is for comparing units under the same conditions. The actual bill depends on the house, the insulation, the settings and how the unit is used; this amount is not a promise.

The house in section

Where will the outdoor unit go? Measure the line, the limits answer

Choose an example or set the refrigerant line length and the height difference between the indoor head and the outdoor unit yourself. Each model shows where your installation falls against what its manufacturer publishes: within the pre-charged length, in the zone where the technician adds refrigerant, or beyond the published maximum.

10 ft30 ft50 ft70 ftdiagram, length not drawn to scale

The examples are rough orders of magnitude, not measurements: the real length is measured on site, along the path of the line.

within the pre-charged length or the published limitrefrigerant to add, up to the published maximumbeyond the published maximumnot published in the documents consulted
Read this before drawing conclusions. In a typical triplex, a head on the third floor and a unit on the ground often call for 40 to 50 ft of line and more than 20 ft of height difference. At 45 ft, the HITACHI airHome 800 stays within its 49 ft pre-charged length, the only one of the four above 40 ft; the other three need refrigerant added, and the TCL ULTIMATE 25 nears its published 50 ft maximum. The KINGHOME POLARIS R32 allows the longest line, 131 ft, but its sheet gives no maximum height difference: that is the figure to confirm before placing the unit. None of these limits says which unit is best; they say which one can go where.
The limits

What each manufacturer sets for installation, line by line

Installation values come from the manufacturers' documents, cited under the value; certified values, from the NEEP records. “Not stated” means the document consulted does not mention it: the limit may exist elsewhere, and must then be confirmed before choosing the location.

Limit or valueHITACHIairHome 800KINGHOMEPOLARIS R32SAMSUNGWindFree MaxHeatTCLULTIMATE 25
AHRI certificate and NEEP recordAHRI 215911631
NEEP 484774Record updated November 6, 2026
AHRI 218451122
NEEP 426104Record updated November 6, 2026
AHRI 215399291
NEEP 389387Record updated November 6, 2026
AHRI 216506201
NEEP 382523Record updated November 6, 2026
Manufacturer listed on the NEEP recordBosch Home Comfort Malaysia Sdn. Bhd.Gree Electric Appliances, Inc. of ZhuhaiSamsung Electronics Co., Ltd.TCL Air Conditioner (ZhongShan) Co., Ltd.
ENERGY STAR, and ENERGY STAR cold climateENERGY STAR Yes
Cold climate Yes
ENERGY STAR Yes
Cold climate Yes
ENERGY STAR Yes
Cold climate Yes
ENERGY STAR Yes
Cold climate Yes
Refrigerant and GWPR-32 · GWP 675R-32 · GWP 675R-32 · GWP 675R-454B · GWP 466
Maximum piping length100 ftMinimum not stated. airHome 800 brochure, December 2024.131 ftMinimum 10 ft. POLARIS R32 specification sheet.66 ftMinimum not stated. Submittal 10072024A.50 ftMinimum 10 ft. Sheet TCL_ULT_050525_1.
Pre-charged length49 ft15 m; 0.11 oz/ft added beyond. Installation manual IA2693:A.25 ftPOLARIS R32 specification sheet.24.6 ftSubmittal 10072024A.25 ftSheet TCL_ULT_050525_1.
Maximum height difference65.6 ftNot stated by the manufacturerThe POLARIS R32 specification sheet consulted gives none.49 ft33 ft
Liquid – gas diameters1/4 – 3/8 in1/4 – 1/2 in1/4 – 3/8 in1/4 – 3/8 in
Outdoor unit W × H × D, weight33.46 × 25.59 × 11.73 in, 91 lb34 3/8 × 21 27/32 × 14 51/64 in, 81.6 lb31 1/8 × 21 9/16 × 11 1/4 in, 71 lb34 × 23 11/16 × 13 3/4 in, 69.4 lb
Electrical protectionMCA 14 A, MOP 25 AMOCP 15 AMCA 12.5 A, MOP 20 AMCA 12 A, MOCP 20 A
Announced heating / cooling range−30 °C to 24 °C / −20 °C to 46 °C−30 °C to 30 °C / −29 °C to 50 °C−30 °C to 24 °C / −18 °C to 46 °C−30 °C to 30 °C / −15 °C to 55 °C
Outdoor unit base pan: what the manufacturer declares150 W, controlled by outdoor temperature (0 °C threshold), per the NEEP record; the brochure links it to adaptive defrost.72 W; turns on below 1 °C (33.8 °F) outdoors or during defrost, per the NEEP record.150 W; starts below −8 °C in heating and stops above −7 °C, per the NEEP record.150 W; turns on below 0 °C outdoors, per the NEEP record.
Snow and clearances: what the documents saySnow protection accessory recommended in cold climates (brochure).Not stated by the manufacturerNothing in the specification sheet consulted.The AR DXD series installation manual has a section on installing in snowy regions.Not stated by the manufacturerNothing in the sheet consulted.
Coldest point published by NEEP−30 °C6,000 BTU/h max. · COP 1.06−30 °C7,300 BTU/h max. · COP 1.51−30 °C6,800 BTU/h max. · COP 1.73−30 °C7,100 BTU/h max. · COP 1.22
SEER2 / EER225.0 / 14.525.5 / 14.524.0 / 14.125.0 / 14.0
HSPF2 Region IV / Region V11.5 / 8.710.0 / 8.010.5 / 8.510.5 / 9.0

Bars: same scale for all four in each line. Ranges: heating in dark, cooling in pale, from −35 to 55 °C. MCA: minimum circuit ampacity; MOP or MOCP: maximum overcurrent protection, in each manufacturer's own term.

Extreme cold

Below −15 °C, every published point, two models at a time

All four NEEP records have a last point at −30 °C, which is also the lower limit of their announced heating range. Between −15 and −30 °C, HITACHI and TCL publish their own values; we show them with their source, with nothing calculated between two points.

See in detail:

A range is not an estimate: it is the two published values that frame the temperature, each with its source. Manufacturer values are outside the certificate.

Questions

Frequently asked questions

Why can an installation be turned down?

When the desired location exceeds a limit the manufacturer publishes, for example a line longer than the maximum or a height difference greater than allowed, the installation would leave the conditions described in its documents. The solution is often another outdoor-unit location or a model whose limits cover the house.

What does “pre-charged length” mean?

The outdoor unit ships filled with refrigerant for a certain line length. Beyond it, the technician adds the amount the manual specifies, up to the published maximum length. HITACHI, for example, states 0.11 oz per foot beyond 49 ft for the airHome 800.

What if a manufacturer publishes no maximum height difference?

The KINGHOME POLARIS R32 specification sheet consulted gives none. It must then be confirmed with the manufacturer or its distributor before setting the units' location; the page marks it “not stated” rather than inventing a figure.

Are the house-section examples measurements?

No. They are rough orders of magnitude for a typical duplex or triplex. The real length depends on the line's path, bends and the units' exact location; it is measured on site.

Why does electrical protection differ from one model to another?

Each manufacturer publishes its unit's minimum circuit ampacity (MCA) and maximum protection (MOP or MOCP). The circuit is sized from the chosen model's document, by an electrician.

What happened to the old article's “refused” brands?

This article was rebuilt in November 2026. It no longer passes judgment on brands; for named models, it shows the limits their manufacturers publish, which anyone can check.

Are these models eligible for LogisVert?

Eligibility depends on Hydro-Québec's list in effect on the day of purchase, which can change. Each model's AHRI certificate number is shown above so you can check it.

What about warranties?

Terms vary by manufacturer, unit registration and retailer; they are not compared here. The warranty documents for the chosen model come with the quote.

All four are on AirGreen's website.

Our estimator comes to your home for free: he measures the room and the wall, looks at where the outdoor unit can go, and you receive a written quote within 24 hours.

Sources

Documents consulted

AHRI certificates 215911631, 218451122, 215399291 and 216506201SEER2, EER2, HSPF2, capacities · read through each model's NEEP record
NEEP, cold climate heat pump list (ashp.neep.org)Records 484774, 426104, 389387 and 382523 · ENERGY STAR, listed manufacturer, base pan heater · consulted November 17, 2026
HITACHI, airHome 800 brochure (French and English)Johnson Controls-Hitachi, “December 2024_CA” · piping, height difference, ranges, snow, capacities at −20 and −25 °C
HITACHI, installation manual IA2693:APre-charged length of 15 m, 0.11 oz/ft added
KINGHOME, POLARIS R32 specification sheetFrench and English versions, undated · piping, pre-charge, ranges, protection
SAMSUNG, WindFree Max Heat 12K submittalAR12DXDABWKNCV / AR12DXDACWKXCV, version 10072024A · piping, pre-charge, height difference
SAMSUNG, RAC R32 Technical Data Book for North AmericaVersion 1.2 dated 2025-06-27 · dimensions, protection, ranges
SAMSUNG, AR DXD series installation manualInstallation in snowy regions
TCL, ULTIMATE 25 SERIES sheetTCL_ULT_050525_1, © 2025 TCL North America · piping, ranges, capacity at −25 °C
Hydro-Québec, Electricity RatesApril 1, 2026, Rate D, sec. 2.5
NRCan, HOT2000 climate map, Montréal IntlHeating degree-days and design temperature
