Wall heat pumps and refrigerant: R-32 or R-454B, BOSCH, FUJITSU AIRSTAGE and SHARP compared

13 min
Comparison · R-32 and R-454B refrigerants · 12,000 BTU

R-32 or R-454B: what the refrigerant changes, with the manufacturers' numbers

The wall heat pumps sold today mostly use two refrigerants: R-32 and R-454B. This page sets three 12,000 BTU wall units sold by AirGreen side by side, in alphabetical order of brand: a BOSCH on R-454B, a FUJITSU AIRSTAGE and a SHARP on R-32. For the refrigerant, the page sticks to three published facts: its name, its global warming potential (GWP, the value from the IPCC Fourth Assessment Report) and its ASHRAE safety class.

2 refrigerants, one class: A2LGWP 466 and 675 (IPCC, AR4)Sources: manufacturers and AHRI certificatesNo ranking
BOSCH Climate 5000 MAX PERFORMANCE R-454B 12,000 BTU wall heat pump BOSCH

Climate 5000 MAX PERFORMANCE 12,000 BTU

R-454B refrigerant
BMS500-AAU012-1AHWXD + BMS500-AAS012-1CSXHD · AHRI 215223282
See the product page
FUJITSU AIRSTAGE ORION XLTH 12,000 BTU wall heat pump FUJITSU AIRSTAGE

ORION XLTH 12,000 BTU

R-32 refrigerant
ASUH12KZAS + AOUH12KZAH1 · AHRI 214888802
See the product page
Estimated operating cost

What the electricity costs, in dollars, winter and summer

AirGreen estimate for the same 12,000 BTU/h zone in Montréal, at Hydro-Québec's Rate D, taxes included. The heat pumps are calculated exactly the same way, with the same method as on all our comparison pages; only their certified efficiencies change. The refrigerant does not enter this calculation: the certificate's efficiencies do. The module shows two of them, in alphabetical order; the table that follows shows all three. Electric baseboards serve as the reference point.

All three models, same settings as above

The table follows the price and hours chosen in the module. Same method, same conditions; only each certificate's HSPF2 Region V and SEER2 change.

Winter · heating

Summer · cooling

Full year

How this amount is calculated
  1. Heat needed over the winter. A zone with a heat loss of 12,000 BTU/h ( kW) at −23.1 °C, Montréal's design temperature: kW × 24 h × 4,167 degree-days ÷ (18 − (−23.1)) = kWh of heat for heating around the clock, all winter. Heating degree-days (18 °C base) and design temperature: Natural Resources Canada, HOT2000 climate data, Montréal Intl station. With fewer hours a day ("Heating" slider), the heat is reduced in the same proportion, for the heat pump and the baseboards alike: a simplification that ignores the recovery after a temperature setback.
  2. Electricity for heating. Heat pump: heat × 3.412 ÷ HSPF2 Region V, the AHRI certificate value published by NEEP. Region V is the coldest in the standard, and its calculation includes the electric backup expected when the heat pump is no longer enough. Electric baseboards: 1 kWh of electricity for 1 kWh of heat.
  3. Electricity for cooling. 12,000 BTU/h ÷ SEER2 × hours a day × 60 days ÷ 1,000: the method of Hydro-Québec's air-conditioning calculator, with the SEER2 seasonal efficiency from the AHRI certificate. The number of hours is a scenario, adjustable above from 1 to 24 h. At 24 h, the calculation assumes rated capacity all day: a maximum, since a variable-speed unit slows down when the room is at temperature.
  4. Price. Hydro-Québec Rate D in effect April 1, 2026: 7.065¢ per kWh up to 40 kWh a day, 11.142¢ above that; the average price, 9.104¢, is the one Hydro-Québec's calculators use. GST and QST included. Network access charges, the same with or without a heat pump, are not counted.

AirGreen method v1.1, November 9, 2026. An estimate is for comparing units under the same conditions. The actual bill depends on the house, insulation, settings and use; this amount is not a promise.

The refrigerant

Two refrigerants, one safety class

The refrigerant is the fluid that carries heat between the outdoor unit and the indoor unit. Here, for each one, are its composition, its GWP according to the IPCC Fourth Assessment Report (AR4) and its ASHRAE 34 class. These are properties of the gas: on their own, they say nothing about a unit's efficiency.

R-454BBlend of two components · trade name Opteon XL41 (Chemours)
A2L
BOSCH Climate 5000 MAX PERFORMANCE
2components
  • 68.9% R-32 (difluoromethane)
  • 31.1% R-1234yf, by mass
  • Temperature glide of about 1.5 K according to Chemours: it is a zeotropic blend.
100-year GWP (IPCC, AR4)466
R-410A, 2,088 (reference)
R-32Single component · difluoromethane, CH₂F₂
A2L
FUJITSU AIRSTAGE ORION XLTHSHARP ZU1
1component
  • 100% R-32 (difluoromethane)
  • Pure substance: no temperature glide.
100-year GWP (IPCC, AR4)675
R-410A, 2,088 (reference)

Reading the A2L class. In ASHRAE Standard 34, the letter A stands for the lowest toxicity class and 2L for lower flammability. R-410A, the refrigerant of the previous generation, is only a reference point on the GWP scale: none of the three heat pumps on this page uses it.

How much refrigerant is in the circuit?

Each manufacturer charges the outdoor unit at the factory for a given piping length, then states how much to add per foot beyond it. Set the length between the two units: the bars follow each manufacturer's formula, up to its maximum published length.

25 ft
factory chargeadded according to lengthfactory charge not published (hatching has no value)scale: 0 to 50 oz

The actual amount depends on the installed length; the installer calculates it from the manufacturer's manual. For A2L refrigerants, appliance safety standards (UL/CSA 60335-2-40) set the charge according to the room's floor area.

Features

What each manufacturer writes, line by line

BOSCH sheet BTC 769208308 B (Jan. 2026) and Climate 5000 brochure; FUJITSU AIRSTAGE brochure FG8153C and 12KZAH1 submittal; SHARP ZU series brochure (RBL A/C) and SHARP installation manual. "Not published by the manufacturer" means the document consulted is silent.

FeatureClimate 5000 MAXORION XLTHZU1
RefrigerantR-454BR-32R-32
ASHRAE 34 safety classA2LA2LA2L
100-year GWP (IPCC, AR4)466675675
Factory charge35.27 oz (1,000 g) for 24.6 ft2 lb 9 oz (1,150 g) for 49 ftNot published by the manufacturer in the documents consulted
Added per foot beyond0.16 oz/ft0.22 oz/ft0.16 oz/ft
Refrigerant leak detectorYes; A2L sensor built into the indoor unit Climate 5000 brochureNot published by the manufacturerNot published by the manufacturer
Wi-FiCompatible with the Bosch Connected Control Wi-Fi thermostat Climate 5000 brochureYes; built in, AIRSTAGE Mobile appYes; built in
Heated base panYes; 150 W Declared to NEEPYes; 150 W Declared to NEEPNot published by the manufacturer; the brochure describes the "Hot Gas Pipe" system, which keeps the drain holes free of ice
CompressorRotaryInverterNot named in the brochure; minimum and maximum capacities certified by NEEP
Remote controlIncluded, model 8-733-969-088Wireless, backlit, includedNot published by the manufacturer in the brochure consulted
Deep cold

Below −15 °C, what each manufacturer and NEEP publish

R-32 or R-454B, the heat delivered in deep cold is read in each unit's documents. Dots come from NEEP certificates, diamonds from the manufacturers' sheets; between two published temperatures, the table gives the range, with nothing calculated in between.

One shared temperature at −15 °C; after that, each at its own. NEEP certifies the BOSCH down to −30 °C, the ORION XLTH down to −26.1 °C and the ZU1 down to −27.2 °C. At −30 °C, the BOSCH sheet also gives 6,278 BTU/h with 70 °F indoors, against 5,900 BTU/h on the certificate: the two values come from different conditions, and the certificate prevails.
Sound

Indoor unit noise, according to each manufacturer

Each dot is a level published for one fan speed. BOSCH publishes five speeds, from Silent to Turbo, without stating the measurement method; FUJITSU AIRSTAGE and SHARP publish one level per speed in cooling.

Indoor unit

dB(A), from lowest to highest

dB

The gas has nothing to do with it. What you hear in the room comes mostly from the indoor unit's fan. Whether the circuit holds R-32 or R-454B moves none of these dots.

One line per manufacturer. BOSCH does not state its measurement method; FUJITSU AIRSTAGE and SHARP publish in cooling. Each line is read on its own.

Three sheets, three ways of measuring: a gap of a few decibels between brands is not read as a real difference.

Installation

On your wall, and between the two units

The three indoor units are drawn at their published width. Set the free width of your wall: the lane turns yellow when the unit is wider than the space.

42 in

Each lane stands for 60 in of wall; the light zone in the centre is the chosen free width. Widths: BOSCH sheet BTC 769208308 B, brochure FG8153C, SHARP ZU series brochure.

InstallationClimate 5000 MAXORION XLTHZU1
Maximum piping length82 ft82 ft65.6 ft SHARP installation manual
Precharged length24.6 ft; 0.16 oz/ft beyond49 ft; 0.22 oz/ft beyond25 ft; 0.16 oz/ft beyond
Maximum height difference49.2 ft66 ft32.8 ft
Liquid – gas diameters1/4 – 3/8 in1/4 – 3/8 in1/4 – 3/8 in
Indoor unit W × H × D, weight31.42 × 11.85 × 9.21 in, 22.93 lb38 9/16 × 11 × 9 7/16 in, 28 lb34 39/64 × 11 3/8 × 9 1/64 in, 22 lb
Outdoor unit W × H × D, weight31.69 × 21.81 × 12.99 in, 72.75 lb31 7/16 × 24 7/8 × 11 7/16 in, 86 lb30 23/32 × 21 1/4 × 10 19/32 in, 67 lb
Electrical protection15 A maximum fuse; MCA 15 A15 A15 A maximum fuse
Dehumidification1.2 L/h 2.53 pints/h in the sheet1.9 L/h1.5 L/h 3.2 pints/h in the brochure
Stated heating / cooling range−30 to 24 °C / −30 to 50 °C−26 to 24 °C / −10 to 50 °C−27 to 24 °C / −10 to 46 °C
Certified data

The values on the three certificates

The "Refrigerant" row is the only one that touches the topic of this page; all the others describe what the complete unit does. AHRI certificates published by NEEP, consulted November 17, 2026.

Certified valueClimate 5000 MAXORION XLTHZU1
Certificate
AHRI certificate · NEEP record215223282 · 392021214888802 · 392122213194987 · 507399
RefrigerantR-454BR-32R-32
ENERGY STAR · cold climateYes; per NEEPYes; listing 3554345Yes; listing 3414510
Seasonal efficiencies
SEER225.430.522
EER213.41612.5
HSPF2 Region IV10.512.711
HSPF2 Region V810.19
Heating, same test temperatures
Capacity at 8.3 °C, min. / rated / max. (BTU/h)3,800 / 12,000 / 16,0003,500 / 16,000 / 23,6003,200 / 14,000 / 17,100
COP at 8.3 °C, min. / rated / max.4.84 / 3.74 / 3.355.13 / 4.64 / 3.076.25 / 3.98 / 2.78
Capacity at −8.3 °C, min. / rated / max. (BTU/h)5,300 / 12,000 / 12,8002,200 / 10,000 / 18,7003,800 / 14,500 / 14,500
Capacity at −15 °C, min. / rated / max. (BTU/h)4,100 / 11,500 / 11,5001,950 / 16,600 / 16,6002,950 / 12,000 / 12,000
COP at −15 °C, min. / rated / max.1.72 / 1.80 / 1.803.36 / 2.16 / 2.162.88 / 2.11 / 2.11
Coldest point on each certificate (different temperatures)
Test temperature−30 °C (−22 °F)−26.1 °C (−15 °F)−27.2 °C (−17 °F)
Max. capacity (BTU/h)5,90012,2007,200
COP at max. capacity1.251.811.80

Nothing is highlighted. The three last points are taken at −30, −26.1 and −27.2 °C: three temperatures, so three rows not to line up. Capacities and COPs are only compared at the shared test temperatures.

Questions

What we get asked about refrigerant

Are R-454B and R-32 the same thing?

No. R-32 is a pure substance, difluoromethane. R-454B is a blend: 68.9% R-32 and 31.1% R-1234yf, by mass, according to Chemours. Both are classified A2L under ASHRAE Standard 34. Their GWP according to the IPCC Fourth Assessment Report is 675 for R-32 and 466 for R-454B.

What does A2L mean?

It is the ASHRAE 34 safety class: A for the lowest toxicity class, 2L for lower flammability. These units and their installation follow rules specific to these refrigerants. BOSCH states, in its Climate 5000 brochure, an A2L sensor built into every indoor unit; the FUJITSU AIRSTAGE and SHARP documents consulted do not mention one for these models.

Can another refrigerant be added to the unit?

No. BOSCH writes that its R-454B units are designed for that refrigerant only and that no other may be mixed in. An R-32 unit is recharged with R-32. This is work for a technician trained on A2L refrigerants.

Does the refrigerant change the bill?

Not directly on this page: the cost module uses each unit's certified efficiencies (HSPF2 Region V and SEER2), with the same method for all three. It is the complete unit that is certified, not the gas alone.

Why a BOSCH wall unit and not the BOSCH IDS Premium from the old article?

The IDS Premium is a central heat pump, with a ducted indoor unit. To compare units of the same type and capacity, the page uses the 12,000 BTU BOSCH Climate 5000 MAX PERFORMANCE wall unit, also on R-454B.

Does the refrigerant change the warranty?

The page does not compare warranties. Their terms depend on the manufacturer, registration and purchase date; the documents for the chosen model come with the quote.

Is an R-454B unit more eligible for LogisVert?

The refrigerant is not what decides here: eligibility follows Hydro-Québec's list in effect on the day of purchase, for the exact model. We check it in the quote; no amount is promised on this page.

All three are on AirGreen's website.

Our estimator comes to measure the room, the wall and the piping route between the two units for free. Written quote within 24 hours.
