Is it the right size for your home?
It delivers 133 cfm net, enough to ventilate 1,600 to 2,500 sq ft. Choose your home's living area.
It's the right size.
For a 1,500 to 2,500 sq ft home, about 105 cfm of air needs to be renewed continuously. This unit delivers 133 cfm net — enough for the house, with extra capacity to boost ventilation for the bathroom and kitchen.
Calculation: 0.35 air changes per hour over the living volume, with 9 ft ceilings. Our estimator sets the exact airflow room by room, following CSA F326.
What it does, in numbers
$17.57
Electricity per year
Less than a 60 W light bulb
Bulbs left on day and night. Same calculation for every line: wattage × 8,760 h × 11.142 ¢/kWh.
Meets the Québec Construction Code everywhere in the province. The Code requires 54% at −25 °C below 6,000 degree-days (Montréal, Laval, Longueuil and both shores) and 60% above that. This unit is rated at 63% at 66 cfm.
Airflow and efficiency at 0 °C and −25 °C: HVI directory, Section III. Cost: 18 W over 8,760 h at Hydro-Québec's Rate D second tier (11.142 ¢/kWh).
What you should know about this one
Published, verifiable facts, not brochure claims.
NovoclimatNovoclimat-compliant with the Advanced control
Per its spec sheet, this ERV meets Novoclimat requirements when paired with the Advanced Touchscreen wall control. Plan for it at the quote stage for a home aiming at this Québec certification.
Plus modePlus mode: longer defrost for colder regions
Defrost starts at −5 °C. Besides the factory Discretion setting, the installer can choose Plus mode, which extends each defrost to 7 or 8 minutes (5 to 7 minutes in Discretion) for colder areas.
63%What it still recovers at −25 °C
The only efficiency figure that matters for a Québec winter, and the one the Code uses. An efficiency quoted without its temperature means nothing; this one is measured at a test airflow of 66 cfm.
DamperIt defrosts without depressurizing the house
In cold weather, a motorized damper closes the outdoor air intake and recirculates indoor air through the core to thaw it. The house doesn't go into negative pressure during the cycle: no cold air drawn in through leaks, and none of the imbalance manufacturers warn about when there's a fireplace or a combustion appliance.
ERVIt moves moisture too, not just heat
An ERV transfers some moisture between the two airstreams. Useful in a house that gets too dry in winter or takes on a lot of humidity in summer. The trade-off: it generally recovers less heat than a comparable HRV.
2005456Its HVI certification number
Listed in Section III of the Home Ventilating Institute's certified products directory. Anyone can check it, and it's the first condition for the Rénoclimat grant.
−7 cfmWhat the ducts cost it
Between a nearly unrestricted test bench (0.2 in) and a real duct system (0.4 in), it drops from 140 to 133 cfm. Most spec sheets show only the first number, precisely because it looks better.
18 WMeasured at the airflow it actually runs at
Its 81% at 0 °C is certified at 36 cfm, the continuous airflow of a typical home. At that setting it draws 18 W, or about 158 kWh a year.
5 yearsThe core warranty
The core does the work and is the most expensive part to replace. Motors and parts: 5 years. We register the warranty in your name at commissioning.
6 inWhat it needs on site
6 in ducts, top connection. It weighs 37 lb, and it needs enough clearance to slide the core out once a year.
Rénoclimat: $500 to install or replace an HRV or ERV
First condition met: HVI Section III certified, No. 2005456. Second: your EnerGuide rating must improve between the two evaluations. Québec warns that an air exchanger installed on its own can increase a home's energy use; that's why we balance it to the calculated airflow rather than running it at full speed.
What it needs on site
In a condo with no floor drain, or with little ceiling clearance, we usually look at a side-port model instead. Our estimator checks the location, the drain and the duct route before ordering.
Complete spec sheetData and cited sources
- Net airflow at 0.2 in. w.g.
- 140 cfm
- Net airflow at 0.4 in. w.g.
- 133 cfm
- SRE at 0 °C (36 cfm)
- 81%
- SRE at −25 °C (66 cfm)
- 63%
- ASE at 0 °C
- 88%
- Power draw
- 18 W
- Efficacy
- 2.0 cfm/W
- Type
- ERV
- Connection
- Top ports
- Duct collars
- 6 in
- Defrost cycle
- Recirculation (motorized damper)
- Filters
- Washable MERV 8 filter and exhaust filter included; optional disposable MERV 13 filter (V24285)
- Dimensions (L × D × H)
- 21 × 16.13 × 21.5 in
- Weight
- 37 lb
- Power supply
- 120 V
- HVI certification (Section III)
- 2005456
- Warranty — core
- 5 years
- Warranty — motors
- 5 years
- Warranty — parts
- 5 years
Net airflow, efficiency at 0 °C and −25 °C, and power draw: Home Ventilating Institute certified products directory, Section III (HVID 2005456). Annual consumption calculated at 18 W running continuously for 8,760 h, at Hydro-Québec's Rate D second tier (11.142 ¢/kWh), in effect since April 1, 2026.
The next model down and up
Talk to an HVAC technician before you choose
We calculate the airflow room by room, check the location and the drain, and give you an installed price. Balancing is measured at commissioning, not estimated.
AirGreen Presents: The Broan-NuTone V160E75RT — An Intelligent ERV for Superior Air Quality
At AirGreen Air Conditioning & Heating, we know that a good HVAC system is not limited to just heating and cooling. In a modern, well-insulated, and efficient home, indoor air quality plays an essential role in comfort, health, and energy efficiency. That’s why we are proud to present the Broan-NuTone V160E75RT, a ERV air exchanger designed to provide reliable, intelligent ventilation tailored to residential needs in Montreal, Laval, Longueuil, on the North Shore and South Shore.
The Broan-NuTone V160E75RT is part of Broan-NuTone’s AI series, a range designed to simplify installation, improve airflow consistency, and offer a more stable residential ventilation experience. Thanks to its Virtuo Air TechnologyMC, this model allows automatic adjustment of airflow while maintaining consistent performance over time.
Why choose the Broan-NuTone V160E75RT?
The V160E75RT is not just a simple air exchanger. It is a ERV – energy recovery ventilator – designed to renew indoor air while recovering some of the energy contained in the exhausted air. This helps contribute to indoor comfort, especially in well-insulated residences where air can quickly become stagnant.
This model offers a capacity of 140 PCM / CFM at 0.4”, with a maximum sensible recovery efficiency of 81.0%. This combination makes it a very interesting solution for homes that require a constant supply of fresh air without unnecessarily compromising indoor comfort.
An intelligent technology with Virtuo Air TechnologyMC
One of the great advantages of Broan-NuTone V160E75RT is its automatic balancing system. Thanks to Virtuo Air TechnologyMC, the system automatically calibrates and maintains the selected airflow. This means the device can adjust its operation to keep ventilation stable without requiring the complex manual adjustments often associated with traditional air exchangers.
For installers as well as homeowners, this technology represents a real advantage: more precise installation, more consistent operation, and greater peace of mind.
Airflow adapted to the home's needs
The V160E75RT offers an airflow of up to 140 CFM, making it suitable for various residential configurations. Its system allows selecting the desired airflow according to the home's needs to ensure effective air renewal.
Whether for a single-family home, a renovation, a recent construction, or a residence where humidity and air quality need better control, this model offers a flexible and efficient solution.
An ERV designed for comfort and efficiency
Unlike an HRV, which mainly recovers sensible heat, an ERV also allows moisture exchange between airflows. This can be especially useful in homes where better indoor comfort management is desired, especially during transition seasons or when the house is very airtight.
The Broan-NuTone V160E75RT thus helps maintain a more comfortable indoor environment by promoting fresh air intake while limiting energy losses associated with ventilation.
Recirculation defrosting: a practical solution for Quebec’s climate
Quebec’s climate imposes demanding conditions on ventilation systems. In winter, air exchangers must be able to operate efficiently despite cold temperatures. The V160E75RT is equipped with a recirculation defrost cycle, an important feature to reduce the risk of frost buildup inside the unit.
This type of defrosting allows the unit to continue protecting its exchange core while maintaining stable performance when outdoor conditions become more challenging.
Vertical installation with top connection
The Broan-NuTone V160E75RT features a vertical connection, with ports located on the top of the unit. This setup is especially convenient in many residential installations, particularly when mechanical space is limited or when duct configuration favors a vertical outlet.
Its compact dimensions of 21.00 × 16.30 × 21.50 inches allow effective integration into various mechanical spaces while maintaining respectable ventilation capacity.
Reliable construction for long-lasting use
Broan-NuTone is a recognized brand in residential ventilation. The V160E75RT is designed to offer lasting performance, with a sturdy construction and components intended for daily residential use.
This model operates on a 115 V, which corresponds to a standard electrical setup for many residential installations. Its design aims to simplify integration into homes while ensuring reliable operation.
Filtration and indoor air quality
A good air exchanger is not just for expelling stale air: it also helps bring filtered fresh air into the home. The Broan-NuTone V160E75RT helps improve indoor air quality by reducing the buildup of moisture, odors, and household pollutants.
For families who spend a lot of time indoors, or for well-insulated homes where air circulates less naturally, a system like this can make a big difference every day.
Main technical features
Model: Broan-NuTone V160E75RT
Type of air exchanger: VRE
Energy Star: No
Voltage: 115 V
Dimensions: 21.00 × 16.30 × 21.50 in
Manufacturer’s warranty: 5-1-0
Defrost cycle: Recirculation
Maximum sensible recovery efficiency: 81.0%
Airflow: 140.0 CFM at 0.4”
Connection: Vertical
Port configuration: Top
Why have your VRE installed by AirGreen?
Choosing the right air exchanger is important, but its installation is even more so. A poorly installed or unbalanced VRE can lead to ineffective ventilation, humidity problems, energy losses, or discomfort in the home.
At AirGreen, our team installs ventilation, air conditioning, and heating systems throughout the greater Montreal area. We take the time to assess the home's layout, existing ducts, ventilation needs, and space constraints to propose a clean, durable, and efficient installation.
Our goal is simple: to offer a solution that works well, respects the home's requirements, and truly improves indoor comfort.
An excellent choice for modern homes
The Broan-NuTone V160E75RT is particularly interesting for homeowners looking for a high-performance, smart, and compact ventilation solution. Thanks to its capacity of 140 CFM, its sensible recovery efficiency of 81%, its recirculation defrost and its Virtuo technology, it represents a solid option to improve indoor air quality while maintaining good energy efficiency.
In modern homes, where insulation and airtightness are increasingly important, a quality air exchanger becomes essential. The V160E75RT meets this need with an intelligent and reliable approach.
In conclusion
The Broan-NuTone V160E75RT is much more than just an air exchanger. It is a residential ventilation solution designed to improve comfort, support better air quality, and offer stable performance in Quebec’s climate conditions.
With its flow rate of 140 CFM, its VRE core, its maximum sensible recovery efficiency of 81.0%, its recirculation defrost cycle and its vertical connection, this model fits perfectly into a modern residential comfort strategy.
For professional installation in Montreal, Laval, Longueuil, on the North Shore or the South Shore, trust AirGreen Air Conditioning & HeatingOur team supports you in choosing, installing, and maintaining your ventilation system to ensure optimal performance year after year.
