PTAC AMANA | 9,000 BTUs | HEC (HIGH EFFICIENCY) R410A K
Is it the right size for this room?
Amana doesn't publish a room size for this unit. From its 9,200 BTU/h of cooling, we estimate ≈ 125 to 190 sq ft. Choose your room's area.
It's the right size.
For a 130 to 175 sq ft room, this is the range we estimate for this unit: 9,200 BTU/h of cooling and a heater of up to 5,000 W when the cold calls for it.
AirGreen estimate: Amana publishes no room size, so we apply the application ranges Trane publishes for its PTACs of the same cooling capacity. Our estimator confirms the exact area on site.
What it does, in numbers
$16.94
Cooling, all summer
Less than a 60 W light bulb
Bulbs left on day and night for a year. Cooling: 5 h a day for 40 days, the assumption used by Hydro-Québec's air-conditioning calculator. Same calculation for every line: wattage × hours × 11.142 ¢/kWh.
≈$125
Heating, all winter
Typical 158 sq ft room with one exterior wall, in Montréal: 1,125 kWh of heat per winter (Environment Canada 1991–2020 climate normals).
≈ $142 for the year, before tax. Winter is 88% of it. If your home stays in the first tier of Rate D in summer (7.065 ¢/kWh), cooling drops to $10.74.
Capacities and currents: Amana catalog MC-DPTAC 10-23 (October 2023) and manual IO-933A (December 2022). Power draw: 760 W in cooling (9,200 BTU/h ÷ EER 12.1), 5,000 W on the 5 kW heater. Hydro-Québec Rate D in effect since April 1, 2026: 11.142 ¢/kWh second tier, before tax.
What you should know about this one
Published, verifiable facts, not brochure claims.
9,200What it really delivers in cooling
The name says 9,000 BTU: that's the unit's size class. Amana publishes 9,200 BTU/h at 230 V, a little more than its size class, and 9,000 at 208 V, the supply in many buildings.
5,000 WThe heater that heats the room
At Amana, the two digits after the series letter (the ** in HEC093K**AXXX) set the heater when ordering: 1.5, 2.5, 3.5 or 5.0 kW at 230 V, 1.3 to 4.1 kW at 208 V. At 5.0 kW it takes a 6-30P plug on 30 A; at 3.5 kW, a 6-20P on 20 A. It heats the room all winter.
12.1Efficiency above the standard model
Amana publishes an EER of 12.1 for this HEC, against 11.6 for the standard PTC of the same size. For the same capacity, it draws fewer watts in summer.
2Pints of water it removes per hour
The dehumidification Amana publishes in cooling mode: 2 pints per hour. It's what keeps a room comfortable in summer without it turning clammy.
7⅝ inHow far it sticks into the room
Amana quotes a 7⅝ in deep front, one of the slimmest in the industry: the unit takes less space out of the room.
4 °CRoom freeze protection
As soon as the unit senses 40 °F (4 °C) or below, it starts the fan and the heater: an empty room won't freeze in winter.
6-30PThe outlet it needs
With the 5.0 kW heater: a NEMA 6-30P plug on a dedicated 30 A circuit. With 3.5 kW: 6-20P on 20 A. With 2.5 kW: 6-15P on 15 A. In a replacement, the outlet already in the wall dictates the heater size.
It fits the standard 42 × 16 in sleeve
Amana sleeves have the industry-standard dimensions: 42 in wide, 16 ¹⁄₁₆ in high, 14 ⅛ in deep. Our estimator checks the sleeve and the grille in place before ordering.
What it needs on site
In a replacement, we check the outlet and the breaker first: they set the heater size you can use. Our estimator confirms the sleeve, the outlet and the slope before ordering.
Complete spec sheetData and cited sources
- Model
- HEC093K**AXXX
- Cooling capacity (208/230 V)
- 9,000 / 9,200 BTU/h
- Electric heater (options)
- 1.5 kW · 2.5 kW · 3.5 kW · 5.0 kW
- EER (208/230 V)
- 12.2 / 12.1
- Current — compressor
- 4.2 A
- Airflow (low/high)
- 264 / 330 cfm
- Dehumidification
- 2 pints/h
- Application range
- ≈ 125 to 190 sq ft (AirGreen estimate)
- Front
- 7⅝ in deep
- Sleeve
- 42 × 16 ¹⁄₁₆ in, 14 ⅛ in deep
- Net weight
- 102 lb
- Refrigerant
- R-410A
- Power supply
- 208/230 V · 1 ph · 60 Hz
All values: Amana catalog MC-DPTAC 10-23 (October 2023) and manual IO-933A (December 2022). Operating cost: cooling at 760 W for 200 h per summer; heating estimated for a typical 158 sq ft room (1,125 kWh of heat per winter); at Hydro-Québec's Rate D second tier (11.142 ¢/kWh), in effect since April 1, 2026.
The neighbouring models
Talk to an HVAC technician before you choose
We check the existing sleeve, the outlet and the heater size, and give you an installed price. For a building, we order the same series for every room.
Optimal comfort and energy savings for residential and commercial spaces
At AirGreen, we understand that choosing the right air conditioning and heating system is essential for ensuring comfort, performance, and energy efficiency. The AMANA | 9,000 BTU | HEC (HIGH EFFICIENCY) R410A K PTAC boasts premium design, advanced technology, and durability, making it an ideal choice for hotels, residences, offices, and other environments where performance and reliability must go hand in hand.
Superior energy performance
The AMANA PTAC incorporates high-quality components offering EERs up to 14.0 and COPs up to 3.9 , which allows it to significantly reduce energy consumption. This performance can qualify for various subsidies offered by electricity companies in the Montreal, Laval, Longueuil, North Shore and South Shore regions.
Thanks to its R-410A refrigerant gas and condensate dispersion system, the unit maximizes the efficiency of the cooling cycle while minimizing environmental impact. The dual-motor design (indoor and outdoor) ensures optimal performance in all climatic conditions.
Remarkably quiet operation
Comfort isn't just measured by temperature, it's also measured by quiet sound. This model has been redesigned to be Amana's quietest PTAC ever . Its interior tangential ventilation and sound insulation provide an STC of 29 , reducing noise pollution and ensuring peaceful nights in hotel rooms or quiet days in offices.
Connectivity and smart management
The AMANA PTAC isn't just powerful—it's smart, too. Its built-in Bluetooth® connector allows for quick setup via the Amana mobile app (iOS and Android). It also features a built-in RF antenna for direct connection to the Eden thermostat and Eden Concierge energy management system . The latter can reduce the unit's energy consumption by up to 35% or more , while providing accurate performance monitoring.
A modern and functional design
With its modern Quiet White front design and a front depth of only 7⅝ inches , the PTAC AMANA optimizes space while blending harmoniously into any decor. This compact size allows for zero-clearance installation , ideal for tight spaces.
Certified durability and reliability
Made in the USA at the Waller, Texas, facility and 100% factory tested , every PTAC undergoes rigorous quality control, including leak testing. Its integrated filter dryer protects the compressor by removing moisture, extending the life of the unit.
Additionally, the 5-year limited warranty (parts and labor on select components) provides unparalleled peace of mind, reinforcing investment confidence.
Advanced technologies for tailor-made comfort
Key features include:
-
Frost protection : automatic heating activation below 4°C.
-
30-second fan shut-off delay to maximize the use of conditioned air already produced.
-
Compressor lock to prevent short cycling and extend life.
-
Automatic backup heating in case of heat pump mode failure.
-
Constant fan mode for even air circulation.
-
Centralized control via Eden software for remote monitoring and energy savings.
Ideal applications in the Montreal region
At AirGreen, we have installed the PTAC AMANA | 9,000 BTU | HEC R410A K in several projects in Montreal, Laval, Longueuil, on the North Shore and the South Shore . Whether it's to modernize a hotel, equip rental condos or provide efficient comfort in an office, this model stands out for its versatility and reliability .
Our customers particularly highlight:
-
Reducing energy costs on their monthly bills.
-
Easy maintenance thanks to removable washable filters.
-
Sound comfort , crucial for sensitive environments.
Why choose AirGreen for installation?
By choosing AirGreen, you benefit from:
-
Free on-site estimate .
-
Certified and experienced refrigeration technicians .
-
Transparent prices with no surprises .
-
Payment upon complete customer satisfaction .
We put our HVAC expertise at the service of each project, with personalized support from product selection to post-installation maintenance.
In summary , the PTAC AMANA | 9,000 BTU | HEC R410A K is a high-performance, discreet, durable and intelligent heating and air conditioning solution, perfectly suited to the needs of residential and commercial buildings in the greater Montreal area.
Contact us today for a free estimate and discover how this model can transform your space into a comfortable, energy-efficient, and quiet environment.
