KINGHOME Multi-Zone R32 One-Way Ceiling Cassette | 12,000 BTU

In stock
SKU: KM12XK1DI
12,000BTU/h · nominal capacity
Optional Wi-FiR-3212-yr compressor, 12-yr parts
Talk to a technician · 514 316-2973
Outdoor unitSUR MULTIZONE SEULEMENT
Cassette (indoor)KM12XK1DI
AHRISUR MULTIZONE SEULEMENT

The slim cassette for the basement family room and rectangular rooms

The finished basement is where we install the most ceiling cassettes. The reason is simple: the ceiling is often already dropped or drywalled under the joists, the walls are taken up by furniture, a TV or high windows, and the room is almost always long and narrow. The KINGHOME one-way ceiling cassette, in its 12,000 BTU size, is designed for this kind of space: a slim housing hidden in the ceiling, a discreet linear panel and an airflow directed in a single direction, along the length of the room.

We recommend it for a basement family room, a playroom, a closed kitchen, a long dining room, or a professional office where you meet clients and don't want to see any unit on the wall. In single-family houses in Laval and on the North Shore, it's often the basement head in a project to replace electric baseboards.

A head that only works with an Ultra Heat outdoor unit

This cassette is an indoor unit for a multi-zone heat pump. It has no dedicated outdoor unit, no AHRI number and no efficiency rating of its own: it connects to a KINGHOME Ultra Heat R-32 outdoor unit, which supplies it with 220 V power and refrigerant, just like the other heads in the house. The performance ratings and the certification are those of the complete system.

The 12,000 BTU size is accepted by every outdoor unit in the lineup, according to the manufacturer's compatibility table: KM18X6O (2 zones), KM24X6O (3 zones), KM30X6O and KM36X6O (4 zones), KM42X6O and KM48X6O (5 zones), KM60X6O (6 zones). In a bungalow with a basement, the combination we design most often uses a KM24X6O or KM30X6O unit: a wall-mounted head in the living room, one or two heads in the bedrooms, and this cassette in the basement.

The 18,000 to 48,000 BTU units carry the ENERGY STAR cold climate designation and heat down to -30 °C. The 60,000 BTU unit is the exception: it doesn't have this designation. For a basement, that matters: it's the room that stays cold the longest in spring and that needs heat even when the rest of the house no longer does.

Airflow along the long axis of the room

A basement family room is often two or three times as long as it is wide. A square cassette in the centre blows as much toward the nearby walls as toward the far end of the room. The one-way cassette, mounted at one end, sends all its airflow toward the other end. The far end of the room, the one that stays cold in winter, finally gets its share of air.

The housing is 38.86 in. long by 15.16 in. wide, with a depth of 7.01 in. In a basement, that depth often lets the unit fit between the joists without lowering the ceiling, which preserves headroom that's already limited. The panel, with its closed air intake and wave texture, stays understated, and the manufacturer offers several panel options. The cross-flow blade and the internal air duct throw the airflow far into the room.

What the spec sheet lists

  • Nominal capacity: 12,000 BTU
  • Maximum airflow: 353 CFM
  • Indoor sound level: 34 dB(A) at low speed, 41 dB(A) at maximum speed
  • Dehumidification: 2.96 pt/h, or about 1.4 L/h
  • Housing dimensions: 38.86 x 7.01 x 15.16 in.

Basement humidity, an often-overlooked factor

In July, a basement in Longueuil or Laval doesn't need much air conditioning, but it does need drying out. At 2.96 pt/h, this model removes about 75% more moisture than the 9,000 BTU model in the same series. That's the main reason we choose the 12,000 BTU over the 9,000 BTU in a medium-sized family room: the air stays dry, the musty smell goes away and the portable dehumidifier can often be retired.

On the other hand, we don't oversize. In a closed office or a spare bedroom, the 9,000 BTU is still the better choice. Since the housing is identical across the whole one-way series, the choice is based on the on-site assessment of the room's heating needs, not on the space available in the ceiling.

Controls and features

The infrared remote is included. Wi-Fi is available as an option through a Wi-Fi wired controller compatible with the KINGHOME app; a wall-mounted or recessed wired controller is also available. In a basement, we often recommend the wired controller: it stays on the wall, within reach, and doesn't get lost between the couch cushions. The I-feel function, coil self-cleaning, forced defrost, soft start and low-voltage start-up round out the features, along with a frost-protection maintenance heating mode.

What we check before the installation

Every basement has its surprises: a steel beam, a main drain pipe, a furnace duct running across the ceiling. During our visits in Montréal, Laval, Longueuil, on the North Shore and on the South Shore, we confirm these points before we quote.

Structure and access

We locate the joists, the obstacles and the clear space above the ceiling. The housing is hung from the structure with threaded rods, with the manufacturer's clearances. In a drywall ceiling, we plan the exact opening and a service access for the pump and the connections.

Electrical supply

The head is powered through the outdoor unit; it's the outdoor unit that determines the circuit in the panel. The KM24X6O requires an MCA of 20 A and an MOP of 25 A; the KM30X6O, an MCA of 23 A and an MOP of 35 A. In a baseboard replacement project, the electrical load that's removed often frees up room in the panel, but we do the full assessment before confirming.

The outdoor unit

It's mounted on a wall bracket, above the accumulated snow and away from roof downspouts, so defrost water can drain and the unit doesn't end up encased in ice after a storm.

Piping and drain

The ports on the 18,000 to 48,000 BTU units are 1/4 and 3/8 in. In a basement, the piping run is usually short, which is a real advantage. The built-in condensate pump lifts the cooling water to a floor drain, a sump or a plumbing stack: we confirm this discharge point and test the drainage at start-up. The vacuum is pulled all the way, no shortcuts.

LogisVert assistance

This indoor head doesn't appear by itself on Hydro-Québec's LogisVert assistance list; eligibility is confirmed on the installation date. The assistance is tied to the complete multi-zone system: its indicative amount is calculated using the LogisVert rule ($120 per 1,000 BTU/h of certified heating capacity at -8.3 °C, or $50 with the KM60X6O, which has no cold climate designation), based on the Ultra Heat outdoor unit and the certified combination. We confirm it for your project when we prepare the quote. Only Hydro-Québec confirms the assistance granted.

Why go with AirGreen

  • Salaried refrigeration technicians who install the cassettes and outdoor units themselves.
  • Civil liability insurance of $5,000,000.
  • Warranty registration taken care of by us.
  • After-sales service that follows your multi-zone system over time.

Ask for your free estimate: we measure your basement, do an on-site assessment of each room's heating needs and recommend the right multi-zone system, cassette included.

Documentation

Warranty: 12 years on the compressor, 12 years on parts and 6 years on labour, directly from the distributor, on registered models; additional warranty available.
