Do I need a snow hood or wind baffle on the outdoor unit?

Fujitsu offers both. The baffle helps the unit run in high wind, especially on a roof; the hood keeps snow from building up inside the unit. We pick the model for your unit and its location.

Does my outdoor unit have a base pan heater?

The Orion XLTH, Orion XLTH+ and J-7S have one built in: nothing to add. For other models, we check Fujitsu’s sheet for your unit.

Which electric heater kit for my AMUH?

Fujitsu offers two or three per size, from 2 kW (AMUH12) to 16 kW (AMUH48), in one or two stages, at 208/240 V. The choice depends on your heating load and electrical service.

Can a cassette blow on one less side?

Yes. A Fujitsu shutter plate closes one outlet: UTR-YDZB for the compact cassette, UTR-YDZK for the circular-flow cassette.

Can a cassette bring in fresh air?

Yes, with Fujitsu’s fresh air intake kit: UTZ-VXAA for the compact cassette, UTZ-VXRA for the circular-flow cassette.

How do I connect the heat pump to the building system?

Fujitsu offers a Modbus converter (UTY-VMSX), a BACnet MS/TP and Modbus RTU gateway (FJ-AC-485-1), input/output boards, and a converter to a VRF network (UTY-VTGX).

Does the circular-flow cassette need a condensate pump?

No. It has a built-in drain pump.

What warranty on parts and accessories?

Fujitsu warrants wired controls for three years. Wireless controls and accessories are warranted for 90 days.

Do accessories qualify for a rebate?

No. LogisVert funds the complete heat pump, not accessories or electric elements.

FUJITSU AIRSTAGE · PIÈCES ET ACCESSOIRESFUJITSU parts at AirGreenAuthorized dealer at the highest level of the AIRSTAGE Elite program.

Elite Plus

Genuine Fujitsu parts10 families

Fujitsu parts · updated October 8, 2026

FUJITSU parts and accessories: the right part for your unit.

Cassette grilles and kits, heater kits for the air handler, receivers, building gateways and winter parts. Each Fujitsu part fits certain units only: find yours by your indoor unit’s model.

Find my part Book my free estimate

16 kWof electric backup at most, on the largest AMUH air handler.

3winter parts at Fujitsu: snow hood, wind baffle, hail guard.

1gateway for both BACnet MS/TP and Modbus RTU: the FJ-AC-485-1.

The right part, genuine

Kits, receivers, gateways, cassette and air-handler parts: Fujitsu parts, chosen for your unit.

53parts in the catalogue

10part families

8cassette accessories

2AMUH filter-base sizes

AirGreen × FUJITSU AIRSTAGEGenuine partsCassette kitsAMUH heater kitsBACnet and Modbus gatewaysWinter partsElite Plus dealer

01 · What to know

A Fujitsu part is a choice.

Six facts from Fujitsu’s sheets and pages. Sources are at the bottom of the page.

Winter

Fujitsu sells a snow hood, a wind baffle and a hail guard for its outdoor units; its spec sheet pairs them with the 12,000 BTU/h compact cassette system.

Wind

According to Fujitsu, a wind baffle helps the unit in high wind, especially on a roof, but it doesn’t improve cooling in cold weather.

3-way

A Fujitsu cassette can blow on three sides only, with a shutter plate.

Black or white

The circular-flow cassette has a built-in drain pump and a grille in white or black.

16 kW

The largest AMUH air handler takes up to 16 kW of backup heat.

BACnet

A single Fujitsu gateway speaks both BACnet MS/TP and Modbus RTU.

02 · Find your part

Pick your unit.

The indoor unit’s model is on its nameplate. Pick its family: you see the parts Fujitsu names for it.

Find the part for your unit

Item	What it does
UTZJUXA	Genuine Fujitsu kit; we confirm its use for your unit before ordering.
UTYXWZXZL	Connection cable for refrigerant leak detection; model confirmed before ordering.
UTYSGZU	Accessory for the refrigerant leak detection system; model confirmed before ordering.
UTD-GXTA-W, UTD-GXTB-W, UTD-GXTC-W	Auto-louver grille for a ducted unit; model confirmed for your unit.
UTY-VTGX	Converter that links an AIRSTAGE H-Series heat pump to a VRF system’s control network.
UTY-TTRXZ1	Interface that lets a 24 V thermostat run a Fujitsu heat pump; it must be the only control.
UTY-TERX	Controller that lets an external switch run the unit.
UTY-VMSX	Converter that connects an AIRSTAGE heat pump to a Modbus network.
FJ-AC-485-1	Intesis gateway that links the heat pump to a building management system, over BACnet MS/TP or Modbus RTU.
UTR-YDZK	Plate that closes one air outlet on the circular-flow cassette, so it blows on three sides.
UTZ-VXRA	Kit that brings fresh air to the circular-flow cassette.
UTZ-VXAA	Kit that brings fresh air to the compact cassette.
UTR-YDZB	Plate that closes one air outlet on the compact cassette, so it blows on three sides.
UTZ-KXRA	Extra insulation for installing the circular-flow cassette in a humid ceiling.
UTZ-KXGC	Extra insulation for installing the compact cassette in a humid ceiling.
UTY-SHZXC	Occupancy sensor for the circular-flow cassette.
UTZ-GXNA	Bracket that mounts the UTY-XCSX I/O board on the medium-static ducted unit.
UTZ-GXEA	Box that houses the UTY-XCSX I/O board on the compact cassette.
UTZ-GXRA	Box that houses the UTY-XCSX I/O board on the circular-flow cassette.
UTY-XCSX	Board that links the heat pump to another system: remote on/off, run and error signals.
UTY-XCSXZ3	I/O board for the Orion XLTH+ wall unit.
UTY-XCSXZ2	I/O board for the Altair 500 and Orion XLTH wall units.
UTY-XWZXZ3	Genuine outdoor-unit connector; use confirmed for your unit.
UTY-TWRXZ4	Kit that lets a wired controller connect to the Orion XLTH+ wall unit.
UTY-TWRXZ3	Communication kit for a wired controller; model confirmed for your unit.
UTY-TWRXZ2	Kit that lets a wired controller connect to an Altair 500 or Orion XLTH wall unit.
UTY-XWZXZG	Kit to connect an external device to Fujitsu cassettes and ducted units.
UTY-XWZXZ5	Dry contact wire kit for wall units: remote on/off, run and error signals.
UTY-XWZX	Dry contact wire kit: remote on/off and run signal.
FJ-AC-WIFI-1	Intesis Wi-Fi module wired straight to the indoor unit.
FJ-IR-WIFI-1NA	Small wall module that runs the heat pump by infrared, with the Intesis Home app.
UTY-TFSXJ4	Wi-Fi adapter for cassettes, ducted units and air handlers, with the AIRSTAGE Mobile app.
UTY-TFSXH4	USB Wi-Fi adapter for wall heat pumps, with the AIRSTAGE Mobile app.
UTY-XSZXZ1	Wall sensor that reads the temperature in the room rather than in the return air.
UTY-LNXUZ1	Fujitsu wireless remote; model confirmed for your unit.
UTY-LNTU	Wireless remote for the compact cassette.
UTY-LBTUC	IR receiver and wireless remote for the circular-flow cassette.
UTY-LBTUH	IR receiver and wireless remote; model confirmed for your unit.
UTY-LBTUM	IR receiver and wireless remote for ducted units and air handlers.
UTY-RSRY	Simple wall controller with mode choice and a built-in sensor.
UTY-RHRY	Simple wall controller where occupants set the temperature without changing the mode.
UTY-RSRYZ1	Simple wall controller with mode choice and refrigerant-leak alerts.
UTY-RNRUZ6	Touch-screen wall controller with a weekly schedule, refrigerant-leak alerts and emergency heat control.
UTY-RNRUZ5	Touch-screen wall controller with a weekly schedule, replaced by the UTY-RNRUZ6.
UTY-RVRU	Wall controller with a colour touch screen and a light ring that changes colour with the mode.
UTG-CCGFGA	Grille for the compact cassette.
UTG-LCGVCW	White grille for the circular-flow cassette. A black version exists (UTG-LCGVCB).
UTPGU027A, UTPGU060A	Valve kit that shuts off the piping if a refrigerant leak is detected; model confirmed for your system.
UTD-LFNA, UTD-LFNB, UTD-LFNC	Long-life filter for the medium-static ducted unit.
86ET0002, 86ET0001, 86ET0003	Filter base for the AMUH air handler: 16 x 20 in. for 12,000 to 24,000 BTU/h, 20 x 20 in. for 30,000 to 48,000 BTU/h.
UTD-DFMSB1, UTD-DFMMB1	Kit that lets the AMUH air handler install in downflow.
UTZ-EU03MMA to UTZ-EU16MMB2	Backup heater kits from 3 to 16 kW for AMUH 30,000 to 48,000 BTU/h air handlers, on a dedicated circuit.
UTZ-EU02MSA to UTZ-EU08MSB2	Backup heater kits from 2 to 8 kW for AMUH 12,000 to 24,000 BTU/h air handlers, on a dedicated circuit.

Only parts Fujitsu names for a unit are linked to it. A part missing from a list is not necessarily incompatible: we check with you.

03 · Configure your cassette

Grille, 3-way, fresh air, humidity.

Configure your cassette

Compact (ACUH)


Grille	UTG-CCGFGA
3-way airflow	UTR-YDZB
Fresh air	UTZ-VXAA
Humid ceiling	UTZ-KXGC
Inputs and outputs	UTY-XCSX + box UTZ-GXEA
External connect	UTY-XWZXZG
Wireless remote	UTY-LNTU

Submittal sheet of the 12,000 BTU/h compact cassette.

Circular (AUUH)


Grille	UTG-LCGVCW white or UTG-LCGVCB black
One outlet blocked	UTR-YDZK
Fresh air	UTZ-VXRA
Humid ceiling	UTZ-KXRA
Occupancy sensor	UTY-SHZXC
Inputs and outputs	UTY-XCSX + box UTZ-GXRA
Receiver and remote	UTY-LBTUC
Drain	Built-in pump

Submittal sheet of the circular cassette. The black grille is not in our shop yet: we order it at quote time.

04 · The AMUH air handler, part by part

Up to 16 kW of backup.

Pick the air handler size: the heater kits Fujitsu publishes for it.

The electric heater kits

Indoor unit	Fujitsu kits
12,000 BTU/h · AMUH12KUAS	UTZ-EU02MSA · 2 kW — 6,824 BTU/h · 1 stage · breaker field-supplied UTZ-EU04MSB2 · 4 kW — 13,648 BTU/h · 2 stages · breaker field-supplied
18,000 BTU/h · AMUH18KUAS	UTZ-EU03MSA · 3 kW — 10,236 BTU/h · 1 stage · breaker included UTZ-EU06MSB2 · 6 kW — 20,472 BTU/h · 2 stages · breaker field-supplied
24,000 BTU/h · AMUH24KUAS	UTZ-EU02MSA · 2 kW — 6,824 BTU/h · 1 stage · breaker field-supplied UTZ-EU04MSA · 4 kW — 13,648 BTU/h · 1 stage · breaker included UTZ-EU08MSB2 · 8 kW — 27,296 BTU/h · 2 stages · breaker field-supplied
30,000 BTU/h · AMUH30KUAS	UTZ-EU03MMA · 3 kW — 10,236 BTU/h · 1 stage · breaker included UTZ-EU05MMA · 5 kW — 17,060 BTU/h · 1 stage · breaker included UTZ-EU10MMB2 · 10 kW — 34,120 BTU/h · 2 stages · breaker included
36,000 BTU/h · AMUH36KUAS	UTZ-EU03MMA · 3 kW — 10,236 BTU/h · 1 stage · breaker included UTZ-EU06MMA · 6 kW — 20,472 BTU/h · 1 stage · breaker included UTZ-EU12MMB2 · 12 kW — 40,944 BTU/h · 2 stages · breaker included
48,000 BTU/h · AMUH48KUAS	UTZ-EU05MMA · 5 kW — 17,060 BTU/h · 1 stage · breaker included UTZ-EU08MMA · 8 kW — 27,296 BTU/h · 1 stage · breaker included UTZ-EU16MMB2 · 16 kW — 54,592 BTU/h · 2 stages · breaker included

Each kit needs its own circuit, according to Fujitsu. BTU/h = kW × 3,412.

Filter base

86ET0002 (16 × 20 in) for the AMUH12, 18 and 24; 86ET0001 (20 × 20 in) for the AMUH30, 36 and 48.

Downflow

UTD-DFMSB1 for the AMUH12, 18 and 24; UTD-DFMMB1 for the AMUH30, 36 and 48.

Breaker

Some kits have a built-in breaker, others do not: Fujitsu states it kit by kit.

05 · Winter parts

Snow, wind and hail.

Snow hood

“Prevents snow from accumulating inside the outdoor unit,” according to Fujitsu.

Wind baffle

Helps the unit in high wind, especially on a roof. Fujitsu notes it does not extend low-ambient cooling.

Hail guard

Protects the coil from hail, at any angle, according to Fujitsu.

For the AOUH12KUAS1

UTZ-DUSHG3A, UTZ-DUWBG3A and UTZ-DUHGG3A: the only pairing confirmed by a Fujitsu sheet. For other units, we confirm by your model.

Built-in base pan heater

The Orion XLTH, Orion XLTH+, Centauri XLTH and J-7S VRF have one from the factory. It is not sold separately.

Above the snow

Fujitsu calls for a raised support, higher than drifting snow.

Winter parts are not in our shop yet: we add them to your quote.

06 · All families

Ten part families.

Cassette accessories · 8

UTR-YDZK, UTZ-VXRA, UTZ-VXAA, UTR-YDZB, UTZ-KXRA, UTZ-KXGC, UTG-CCGFGA, UTG-LCGVCW

Air handlers and ducted units · 6

UTD-GXTA-W, UTD-GXTB-W, UTD-GXTC-W, UTD-LFNA, UTD-LFNB, UTD-LFNC, 86ET0002, 86ET0001, 86ET0003, UTD-DFMSB1, UTD-DFMMB1, UTZ-EU03MMA to UTZ-EU16MMB2, UTZ-EU02MSA to UTZ-EU08MSB2

Wired wall controls · 6

UTY-RSRY, UTY-RHRY, UTY-RSRYZ1, UTY-RNRUZ6, UTY-RNRUZ5, UTY-RVRU

Wireless remotes and IR receivers · 5

UTY-LNXUZ1, UTY-LNTU, UTY-LBTUC, UTY-LBTUH, UTY-LBTUM

Wi-Fi · 4

FJ-AC-WIFI-1, FJ-IR-WIFI-1NA, UTY-TFSXJ4, UTY-TFSXH4

Sensors · 2

UTY-SHZXC, UTY-XSZXZ1

Communication kits · 3

UTY-TWRXZ4, UTY-TWRXZ3, UTY-TWRXZ2

Dry contacts and I/O boards · 10

UTZ-GXNA, UTZ-GXEA, UTZ-GXRA, UTY-XCSX, UTY-XCSXZ3, UTY-XCSXZ2, UTY-XWZXZ3, UTY-XWZXZG, UTY-XWZXZ5, UTY-XWZX

Building systems and 24 V thermostats · 5

UTY-VTGX, UTY-TTRXZ1, UTY-TERX, UTY-VMSX, FJ-AC-485-1

R-32 safety (leak detection) · 3

UTYXWZXZL, UTYSGZU, UTPGU027A, UTPGU060A

Confirmed before ordering: UTZJUXA, UTYXWZXZL, UTYSGZU, UTD-GXTA-W, UTD-GXTB-W, UTD-GXTC-W, UTY-XWZXZ3, UTY-TWRXZ3, UTY-LBTUH, UTPGU027A, UTPGU060A. For these numbers we found no North American Fujitsu document: we confirm them with the distributor before any order.

07 · Did you know

What Fujitsu’s sheets tell.

Fujitsu sells a snow hood, a wind baffle and a hail guard for its outdoor units.

Source: Fujitsu

According to Fujitsu, a wind baffle doesn’t improve cooling in cold weather.

Source: Fujitsu

The circular-flow cassette grille comes in white and black.

Source: Fujitsu

A Fujitsu cassette can take in fresh air through an intake kit.

Source: Fujitsu

The largest AMUH takes up to 16 kW of backup heat.

Source: Fujitsu

A single Fujitsu gateway speaks both BACnet and Modbus.

Source: Fujitsu

08 · The parts warranty

90 days for accessories, 3 years for wired controls.

Parts have their own Fujitsu warranty, shorter than the heat pumps’.

90 days: accessories

Wi-Fi adapters, IR receiver and external drain pump, as named by Fujitsu.

3 years: wired controls

Simple remote, wired remote, group remote, central remote and KAGAMI.

Installed by AirGreen

We confirm the part, install it and check the operation.

AirGreen × FUJITSU AIRSTAGE

Fujitsu’s part, AirGreen’s installation.

A Fujitsu part fits certain units only. AirGreen checks the model, confirms the part number with the distributor and installs the part.

What FUJITSU AIRSTAGE brings

The right numberFrom your unit’s nameplate.
Confirmed before orderingWith the Fujitsu distributor.
InstalledBy an Elite Plus team.
Genuine partsFujitsu-made, Fujitsu-warranted.

What AirGreen brings

Elite Plus dealerThe highest level of the AIRSTAGE Elite program.
Free home estimateWe measure and check the insulation and the location.
Warranty registered for youWith Fujitsu, within 60 days.
RBQ 5645-9605-01Subclasses 15.8, 15.10 and 16.

The result: the part that fits, the first time.

Book my free estimate Book my free estimate

09 · FUJITSU AIRSTAGE dealer – ELITE PLUS

Elite Plus: the highest level of the AIRSTAGE Elite program.

Fujitsu’s Japanese engineering, installed by an Elite Plus team across Montreal, Laval, Longueuil, the North Shore, the South Shore and Montérégie.

Elite Plus partnership

The highest level of the AIRSTAGE Elite program.

Advanced Fujitsu training

Our technicians take the manufacturer’s training on AIRSTAGE systems.

Careful commissioning

Vacuum, refrigerant settings, electrical hookup, set up for winter.

Genuine parts and Fujitsu support

Manufacturer parts and Fujitsu technical support, wherever we install.

Our FUJITSU AIRSTAGE page

1Home estimate

Free. We measure and check the insulation and the location.

2Clear quote

The model, the size and the indicative LogisVert amount, in writing.

3Installation and commissioning

Vacuum, refrigerant, electrical, winter settings.

4Warranty registered

We register the unit with Fujitsu and help you with LogisVert.

10 · Frequently asked questions

What people ask us about parts.

Read the model number on the indoor unit’s nameplate. Fujitsu publishes the accessory list for each model; we confirm before ordering.

11 · See also

Related collections.

ControlsThermostats and controls

FUJITSU wall controllers and Wi-Fi adapters, with the compatibility guide.

View the collection CentralAir handlers

The FUJITSU electric furnace, which uses the AMUH heater kits.

View the collection Indoor unitCeiling cassettes

FUJITSU cassettes that take these grilles, shutter plates and fresh-air kits.

View the collection Indoor unitDucted units

FUJITSU ducted units, with a long-life filter and an IR receiver.

View the collection VRFVRF systems

The J-7S VRF and its R-32 safety options.

View the collection

AirGreen × FUJITSU AIRSTAGEFree home estimateWarranty registered for youElite Plus dealerMontreal · Laval · Longueuil · South Shore · North Shore

AirGreen · Heating & cooling

Your part, installed by an Elite Plus team.

Send us your indoor unit’s model (on the nameplate): we confirm the right part and install it.

Book my free estimate 514 316-2973

Hydro-Québec does not solicit anyone by phone or door to door for LogisVert. A call “from Hydro-Québec” selling a heat pump: hang up.

RBQ 5645-9605-01Subclasses 15.8, 15.10 and 16

Free estimateAt home, no commitment

Warranty registered for youWith Fujitsu, within 60 days

Showroom1370 Joliot-Curie Street, unit 712, Boucherville

Sources checked on October 8, 2026

28 sources · show

Fujitsu, submittal sheet 12KUAS1C
Fujitsu, submittal sheet 24KUAS1U
Fujitsu, submittal sheet 12KUAS1M
Fujitsu, submittal sheet 24KUAS1M
Fujitsu, submittal sheet 48KUAS1M
Fujitsu, brochure FG8161C
Fujitsu, brochure FG8163C
Fujitsu AIRSTAGE, airstagehvac.com/multi/r32-optionalparts
Fujitsu AIRSTAGE, airstagehvac.com/split/optionalparts
Fujitsu AIRSTAGE, airstagehvac.com/pr/accessories
Fujitsu AIRSTAGE, airstagehvac.com/controller/uty-rvru
Fujitsu AIRSTAGE, airstagehvac.com/controller/uty-rnru
Fujitsu AIRSTAGE, airstagehvac.com/controller/uty-rsryz1
Fujitsu AIRSTAGE, airstagehvac.com/controller/uty-rhry
Fujitsu, technical document assets
Fujitsu AIRSTAGE, airstagehvac.com/r32/knas1
Fujitsu, product or archive page VRF-LEG-OPT
Fujitsu, technical sheet fujitsu_aou36rlavs_article_4651940620724889_en_ii (distributor copy)
Fujitsu AIRSTAGE, document pdf-fcus-h-series-warranty-r32-202606
Fujitsu AIRSTAGE, document pdf-fcus-wi-fi-sell-sheet-01
Fujitsu, submittal sheet 18KUAS1M
Fujitsu, submittal sheet 30KUAS1M
Fujitsu, submittal sheet 36KUAS1M
Hydro-Québec, logisvert guide participation residentiel fr
Régie du bâtiment du Québec, subclass 17.1
U.S. EIA, british thermal units.php
airgreen.ca product sheets, read October 8, 2026
AirGreen, “Nos réalisations” projects blog
